– 146 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
SW
< FUSE >
! F11 1-532-506-31 FUSE (5A/125V)(E,SP,MY,HK,AR)
! F12 1-576-109-21 FUSE (T6.3AL/250V)(US,CND,E)
< FUSE HOLDER >
FH1100 1-533-293-11 FUSE HOLDER (E,SP,MY,HK,AR)
FH1101 1-533-293-11 FUSE HOLDER (E,SP,MY,HK,AR)
FH1200 1-533-293-11 FUSE HOLDER (US,CND,E,HK,AR)
FH1201 1-533-293-11 FUSE HOLDER (US,CND,E,HK,AR)
< IC >
IC11 8-759-604-35 IC M5F78M05L
< TRANSISTOR >
Q11 8-729-119-78 TRANSISTOR 2SC403SP-51
Q12 8-729-040-19 TRANSISTOR RT1N137L-TP
Q13 8-729-118-01 TRANSISTOR 2SB1116
Q14 8-729-040-19 TRANSISTOR 2SC3616-KLM-T1
Q15 8-729-040-19 TRANSISTOR 2SC3616-KLM-T1
Q16 8-729-900-63 TRANSISTOR DTA124ES
Q17 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R11 1-249-429-11 CARBON 10K 5% 1/4W
R12 1-249-441-11 CARBON 100K 5% 1/4W
R13 1-249-417-11 CARBON 1K 5% 1/4W F
R15 1-249-429-11 CARBON 10K 5% 1/4W
R16 1-247-807-31 CARBON 100 5% 1/4W
R17 1-247-807-31 CARBON 100 5% 1/4W
R18 1-247-807-31 CARBON 100 5% 1/4W
R18 1-249-427-11 CARBON 6.8K 5% 1/4W F
(US,CND)
R19 1-249-427-11 CARBON 6.8K 5% 1/4W F
R20 1-249-419-11 CARBON 1.5K 5% 1/4W F
R23 1-249-416-11 CARBON 820 5% 1/4W F
R24 1-249-416-11 CARBON 820 5% 1/4W F
R25 1-247-807-31 CARBON 100 5% 1/4W
R26 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-427-11 CARBON 6.8K 5% 1/4W F
(EXCEPT US,CND)
R31 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
< RELAY >
RY11 1-755-276-11 RELAY, POWER
< TRANSFORMER >
! T11 1-433-832-11 TRANSFORMER, POWER
(E,SP,MY,HK,AR,KR,AUS)
! T11 1-433-833-11 TRANSFORMER, POWER (AEP,UK,G,CIS)
! T11 1-433-835-11 TRANSFORMER, POWER (US,CND)
< POWER SWITCH >
! VS11 1-771-712-11 SWITCH, POWER (VOLTAGE SELECTOR)
(E,SP,MY,HK,AR)
**************************************************************
* 1-671-115-21 SW BOARD
********
< CONNECTOR >
CN601 1-506-486-11 PIN, CONNECTOR 7P
< SWITCH >
S601 1-572-126-21 SWITCH, PUSH (1 KEY)(REC POSITION)
S602 1-572-126-21 SWITCH, PUSH (1 KEY)(PACK OUT)
S604 1-771-264-11 SWITCH, PUSH(DETECTION)(1 KEY)
(PB POSITION)
**************************************************************
1-673-380-11 VOL BOARD
********
< SWITCH >
S602 1-473-392-11 ENCODER, ROTARY (VOLUME)
**************************************************************
MISCELLANEOUS
*************
8 1-775-102-11 WIRE (FLAT TYPE) (11 CORE)
9 1-775-192-11 WIRE (FLAT TYPE) (21 CORE) (150mm)
10 1-775-208-11 WIRE (FLAT TYPE) (23 CORE) (140mm)
13 1-233-544-14 ENCAPSULATED COMPONENT (US,CND)
13 1-233-545-14 ENCAPSULATED COMPONENT (AR,KR,AUS)
13 1-233-546-13 ENCAPSULATED COMPONENT (SP,MY,HK)
13 1-693-443-11 TUNER UNIT (FM/AM) (AEP,UK,G,CIS)
13 1-693-453-11 TUNER UNIT (FM/AM) (E)
54 1-773-043-11 WIRE (FLAT TYPE) (17 CORE)
55 1-773-025-11 WIRE (FLAT TYPE) (15 CORE) (330mm)
56 1-769-976-11 WIRE (FLAT TYPE) (13 CORE)
(US,CND,E,AR,KR,AUS)
56 1-773-008-11 WIRE (FLAT TYPE) (15 CORE) (140mm)
(AEP,UK,G,CIS,SP,MY,HK)
57 1-773-185-11 WIRE (FLAT TYPE) (23 CORE)
59 1-569-007-11 ADAPTOR, CONVERSION 2P (E)
59 1-569-008-21 ADAPTOR, CONVERSION 2P (SP,MY)
59 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
! 60 1-696-845-11 CORD, POWER (AUS)
! 60 1-769-079-11 CORD, POWER (KR)
! 60 1-777-071-41 CORD, POWER (AEP,G,CIS,SP,MY)
! 60 1-777-514-11 CORD, POWER (UK)
! 60 1-782-315-21 CORD, POWER (E)
!60 1-783-820-21 CORD, POWER (US,CND)
! 60 1-783-941-31 CORD, POWER (AR)
65 1-569-972-21 SOCKET, SHORT 2P
67 1-783-570-11 WIRE (FLAT TYPE)(19 CORE)
122 1-675-345-11 WIRE (FLAT TYPE)(23 CORE)
125 1-673-837-21 TC STOPPER A BOARD
126 1-673-838-21 TC STOPPER B BOARD
257 1-452-925-21 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
STANDBY
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
VOL
