Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S756 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EXCHANGE)
S757 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S758 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S759 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S760 1-762-875-21 SWITCH, KEYBOARD (§ (CD))
S761 1-762-875-21 SWITCH, KEYBOARD (§ (MD))
< TRANSISTOR >
Q751 8-729-900-80 TRANSISTOR DTC114ES
Q752 8-729-900-80 TRANSISTOR DTC114ES
Q753 8-729-900-80 TRANSISTOR DTC114ES
Q754 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R749 1-249-407-11 CARBON 150 5% 1/4W F
R751 1-249-410-11 CARBON 270 5% 1/4W F
R752 1-249-411-11 CARBON 330 5% 1/4W
R753 1-249-413-11 CARBON 470 5% 1/4W F
R754 1-249-414-11 CARBON 560 5% 1/4W F
R755 1-249-415-11 CARBON 680 5% 1/4W F
R756 1-249-417-11 CARBON 1K 5% 1/4W F
R757 1-249-418-11 CARBON 1.2K 5% 1/4W F
R758 1-249-420-11 CARBON 1.8K 5% 1/4W F
R759 1-249-422-11 CARBON 2.7K 5% 1/4W F
R760 1-247-843-11 CARBON 3.3K 5% 1/4W
R761 1-249-425-11 CARBON 4.7K 5% 1/4W F
R764 1-247-804-11 CARBON 75 5% 1/4W
R765 1-247-804-11 CARBON 75 5% 1/4W F
R766 1-247-804-11 CARBON 75 5% 1/4W
R767 1-247-804-11 CARBON 75 5% 1/4W F
R768 1-247-804-11 CARBON 75 5% 1/4W
R769 1-247-804-11 CARBON 75 5% 1/4W F
**************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
A-4419-324-A DISPLAY BOARD, COMPLETE (AEP,UK,G,CIS)
***********************
A-4419-497-A DISPLAY BOARD, COMPLETE
***********************
(EXCEPT AEP,UK,G,CIS)
(DISPLAY BOARD is supplied with JOG board and VOL board)
* 4-214-439-11 HOLDER, FL TUBE
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 20% 16V
C604 1-164-294-31 CERAMIC 1000PF 10% 50V
C605 1-162-294-31 CERAMIC 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C608 1-162-294-31 CERAMIC 0.001uF 10% 50V
C609 1-162-294-31 CERAMIC 0.001uF 10% 50V
C610 1-124-589-11 ELECT 47uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 20% 16V
C612 1-162-306-11 CERAMIC 0.01uF 20% 16V
C613 1-162-294-31 CERAMIC 0.001uF 10% 50V
C614 1-162-306-11 CERAMIC 0.01uF 20% 16V
C615 1-162-306-11 CERAMIC 0.01uF 20% 16V
C616 1-126-157-11 ELECT 10uF 20% 16V
C617 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C618 1-126-157-11 ELECT 10uF 20% 16V
C619 1-126-157-11 ELECT 10uF 20% 16V
C620 1-126-163-11 ELECT 4.7uF 20% 50V
C625 1-162-306-11 CERAMIC 0.01uF 20% 16V
C629 1-126-157-11 ELECT 10uF 20% 16V
C651 1-162-282-31 CERAMIC 100PF 10% 50V
C652 1-162-282-31 CERAMIC 100PF 10% 50V
C653 1-162-282-31 CERAMIC 100PF 10% 50V
C654 1-162-282-31 CERAMIC 100PF 10% 50V
C655 1-162-282-31 CERAMIC 100PF 10% 50V
C656 1-162-282-31 CERAMIC 100PF 10% 50V
C657 1-162-282-31 CERAMIC 100PF 10% 50V
C658 1-162-282-31 CERAMIC 100PF 10% 50V
C659 1-162-282-31 CERAMIC 100PF 10% 50V
C660 1-162-282-31 CERAMIC 100PF 10% 50V
C661 1-162-282-31 CERAMIC 100PF 10% 50V
C662 1-162-282-31 CERAMIC 100PF 10% 50V
C663 1-162-282-31 CERAMIC 100PF 10% 50V
C664 1-162-282-31 CERAMIC 100PF 10% 50V
C665 1-162-282-31 CERAMIC 100PF 10% 50V
C666 1-162-282-31 CERAMIC 100PF 10% 50V
C667 1-162-282-31 CERAMIC 100PF 10% 50V
C668 1-162-282-31 CERAMIC 100PF 10% 50V
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-164-159-11 CERAMIC 0.1uF 50V
C731 1-162-306-11 CERAMIC 0.01uF 20% 16V
C732 1-124-257-00 ELECT 2.2uF 20% 50V
C733 1-162-294-31 CERAMIC 0.001uF 10% 50V
C734 1-162-215-31 CERAMIC 47PF 5% 50V
CD PANEL
CONNECTOR
DISPLAY
