Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
C735 1-124-261-00 ELECT 10uF 20% 50V
C736 1-162-290-31 CERAMIC 470PF 10% 50V
C737 1-124-463-00 ELECT 0.1uF 20% 50V
C739 1-162-215-31 CERAMIC 47PF 5% 50V
C741 1-124-261-00 ELECT 10uF 20% 50V
C742 1-162-282-31 CERAMIC 100PF 10% 50V
C743 1-124-257-00 ELECT 2.2uF 20% 50V
C747 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN601 1-568-865-21 SOCKET, CONNECTOR 23P
< DIODE >
D610 8-719-050-84 DIODE RB441QT-77
D611 8-719-057-97 DIODE SEL5923A-TP15 (SYNC BASE H)
D612 8-719-057-97 DIODE SEL5923A-TP15 (SYNC BASE L)
D613 8-719-073-47 DIODE SML72923C-TP15 (REC/PAUSE)
D614 8-719-056-13 DIODE SML79423C-TP15 (MD PLAY/PAUSE)
D615 8-719-056-13 DIODE SML79423C-TP15 (CD PLAY/PAUSE)
D616 8-719-063-93 DIODE SLR325VC-N-T32 (NON STOP)
D617 8-719-063-93 DIODE SLR325VC-N-T32 (ENTER/NEXT)
D618 8-719-057-97 DIODE SEL5923A-TP15 (GROOVE)
D619 8-719-063-93 DIODE SLR325VC-N-T32 (JOG)
D620 8-719-057-97 DIODE SEL5923A-TP15 (+ ))
D621 8-719-057-97 DIODE SEL5923A-TP15 (- 0)
D622 8-719-058-03 DIODE SEL5423E-TP15 (( TAPE B)
D623 8-719-058-03 DIODE SEL5423E-TP15 (9 TAPE B)
D624 8-719-058-03 DIODE SEL5423E-TP15 (( TAPE A)
D625 8-719-058-03 DIODE SEL5423E-TP15 (9 TAPE A)
D626 8-719-057-97 DIODE SEL5923A-TP15 (SYNC EQ)
D627 8-719-063-93 DIODE SLR325VC-N-T32 (EFFECT)
D628 8-719-063-93 DIODE SLR325VC-N-T32 (TIMER SELECT)
D629 8-719-057-97 DIODE SEL5923A-TP15 (SYNC BASE H)
D630 8-719-057-97 DIODE SEL5923A-TP15 (SYNC BASE L)
D631 8-719-057-97 DIODE SEL5923A-TP15 (SYNC EQ)
D632 8-719-063-93 DIODE SLR325VC-N-T32 (EFFECT)
< EARTH TERMINAL >
* E601 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0UH
FB602 1-412-473-21 INDUCTOR 0UH
< FLUORESCENT INDICATOR >
FL601 1-517-841-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-582-73 IC TMP88CS77F-6003
IC602 8-749-011-05 IC GP1U28X
IC603 8-759-083-77 IC BA3830F
IC712 8-759-634-51 IC M5218AP
< JACK >
J701 1-785-569-11 JACK (SMALL TYPE)(HEADPHONES)
J711 1-785-569-11 JACK (SMALL TYPE)(MIX MIC)
< COIL >
L601 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q601 8-729-118-00 TRANSISTOR 2SB1116-L
Q602 8-729-118-00 TRANSISTOR 2SB1116-L
Q603 8-729-119-78 TRANSISTOR 2SC403SP-51
Q604 8-729-900-80 TRANSISTOR DTC114ES
Q605 8-729-900-80 TRANSISTOR DTC114ES
Q606 8-729-900-80 TRANSISTOR DTC114ES
Q607 8-729-900-80 TRANSISTOR DTC114ES
Q608 8-729-900-80 TRANSISTOR DTC114ES
Q609 8-729-900-80 TRANSISTOR DTC114ES
Q610 8-729-900-80 TRANSISTOR DTC114ES
Q611 8-729-900-80 TRANSISTOR DTC114ES
Q612 8-729-900-80 TRANSISTOR DTC114ES
Q613 8-729-900-80 TRANSISTOR DTC114ES
Q614 8-729-900-80 TRANSISTOR DTC114ES
Q615 8-729-900-80 TRANSISTOR DTC114ES
Q616 8-729-900-74 TRANSISTOR DTC143TS
Q617 8-729-900-74 TRANSISTOR DTC143TS
Q618 8-729-900-74 TRANSISTOR DTC143TS
Q619 8-729-900-74 TRANSISTOR DTC143TS
< RESISTOR >
R600 1-247-903-00 CARBON 1M 5% 1/4W
R601 1-247-807-31 CARBON 100 5% 1/4W
R602 1-247-843-11 CARBON 3.3K 5% 1/4W
R603 1-247-807-31 CARBON 100 5% 1/4W
R604 1-247-807-31 CARBON 100 5% 1/4W
R605 1-247-843-11 CARBON 3.3K 5% 1/4W
R606 1-249-401-11 CARBON 47 5% 1/4W F
R607 1-247-893-11 CARBON 390K 5% 1/4W
R608 1-247-889-00 CARBON 270K 5% 1/4W
R609 1-249-441-11 CARBON 100K 5% 1/4W
R610 1-249-429-11 CARBON 10K 5% 1/4W
R611 1-249-441-11 CARBON 100K 5% 1/4W
R612 1-249-401-11 CARBON 47 5% 1/4W F
R613 1-249-435-11 CARBON 33K 5% 1/4W
R614 1-247-895-00 CARBON 470K 5% 1/4W
R616 1-249-441-11 CARBON 100K 5% 1/4W
R617 1-249-441-11 CARBON 100K 5% 1/4W
R618 1-249-441-11 CARBON 100K 5% 1/4W
R619 1-249-441-11 CARBON 100K 5% 1/4W
R620 1-249-429-11 CARBON 10K 5% 1/4W
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-249-410-11 CARBON 270 5% 1/4W F
R623 1-249-411-11 CARBON 330 5% 1/4W
R624 1-249-413-11 CARBON 470 5% 1/4W F
R625 1-249-414-11 CARBON 560 5% 1/4W F
R626 1-249-415-11 CARBON 680 5% 1/4W F
R627 1-249-417-11 CARBON 1K 5% 1/4W F
R628 1-249-418-11 CARBON 1.2K 5% 1/4W F
R629 1-249-420-11 CARBON 1.8K 5% 1/4W F
R630 1-249-422-11 CARBON 2.7K 5% 1/4W F
R631 1-247-843-11 CARBON 3.3K 5% 1/4W
