108
HCD-RV777D/RV888D/RV999D
Ref. No. Part No. Description Remark
Q631 8-729-907-00 TRANSISTOR DTC114EU
Q661 8-729-029-10 TRANSISTOR DTC143TUA-T106
Q662 8-729-905-35 TRANSISTOR 2SC4081-R
Q701 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q702 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q703 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q704 8-729-907-00 TRANSISTOR DTC114EU
Q705 8-729-905-35 TRANSISTOR 2SC4081-R
Q706 8-729-905-35 TRANSISTOR 2SC4081-R
Q707 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q708 8-729-907-00 TRANSISTOR DTC114EU
Q709 8-729-905-35 TRANSISTOR 2SC4081-R
Q710 8-729-905-35 TRANSISTOR 2SC4081-R
Q713 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q714 8-729-907-00 TRANSISTOR DTC114EU
Q719 8-729-028-73 TRANSISTOR DTA114EUA-T106
(RV888D/RV999D)
Q721 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q723 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q724 8-729-028-73 TRANSISTOR DTA114EUA-T106
(RV888D/RV999D)
Q801 8-729-907-00 TRANSISTOR DTC114EU
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R102 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(RV777D)
R111 1-216-864-11 SHORT CHIP 0 (RV888D/RV999D)
R112 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
R114 1-216-833-11 METAL CHIP 10K 5% 1/10W
R115 1-216-821-11 METAL CHIP 1K 5% 1/10W
R116 1-216-841-11 METAL CHIP 47K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-833-11 METAL CHIP 10K 5% 1/10W
R119 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-216-864-11 SHORT CHIP 0 (RV777D)
R131 1-216-864-11 SHORT CHIP 0
R132 1-216-833-11 METAL CHIP 10K 5% 1/10W
R133 1-216-821-11 METAL CHIP 1K 5% 1/10W
R134 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R140 1-216-821-11 METAL CHIP 1K 5% 1/10W
R141 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R142 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R144 1-216-821-11 METAL CHIP 1K 5% 1/10W
R145 1-216-845-11 METAL CHIP 100K 5% 1/10W
R146 1-216-864-11 SHORT CHIP 0
R147 1-216-821-11 METAL CHIP 1K 5% 1/10W
R148 1-216-845-11 METAL CHIP 100K 5% 1/10W
R149 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R150 1-215-890-11 METAL OXIDE 470 5% 2W F
R151 1-216-833-11 METAL CHIP 10K 5% 1/10W
(RV777D)
R151 1-216-864-11 SHORT CHIP 0 (RV888D/RV999D)
R152 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R153 1-216-833-11 METAL CHIP 10K 5% 1/10W
R154 1-216-833-11 METAL CHIP 10K 5% 1/10W
R155 1-216-821-11 METAL CHIP 1K 5% 1/10W
R156 1-216-841-11 METAL CHIP 47K 5% 1/10W
R157 1-216-841-11 METAL CHIP 47K 5% 1/10W
R158 1-216-833-11 METAL CHIP 10K 5% 1/10W
R159 1-216-809-11 METAL CHIP 100 5% 1/10W
R160 1-216-821-11 METAL CHIP 1K 5% 1/10W
R171 1-216-857-11 METAL CHIP 1M 5% 1/10W
R172 1-216-845-11 METAL CHIP 100K 5% 1/10W
R173 1-216-833-11 METAL CHIP 10K 5% 1/10W
R174 1-216-837-11 METAL CHIP 22K 5% 1/10W
R175 1-216-837-11 METAL CHIP 22K 5% 1/10W
R176 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R177 1-216-845-11 METAL CHIP 100K 5% 1/10W
R178 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R179 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R180 1-216-821-11 METAL CHIP 1K 5% 1/10W
R181 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R182 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R184 1-216-821-11 METAL CHIP 1K 5% 1/10W
R185 1-216-845-11 METAL CHIP 100K 5% 1/10W
R186 1-216-864-11 SHORT CHIP 0
R187 1-216-821-11 METAL CHIP 1K 5% 1/10W
R188 1-216-845-11 METAL CHIP 100K 5% 1/10W
R189 1-216-821-11 METAL CHIP 1K 5% 1/10W
0 R190 1-215-890-11 METAL OXIDE 470 5% 2W F
R191 1-216-837-11 METAL CHIP 22K 5% 1/10W
R192 1-216-833-11 METAL CHIP 10K 5% 1/10W
R193 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R194 1-216-821-11 METAL CHIP 1K 5% 1/10W
R195 1-216-845-11 METAL CHIP 100K 5% 1/10W
R196 1-216-837-11 METAL CHIP 22K 5% 1/10W
R197 1-216-841-11 METAL CHIP 47K 5% 1/10W
R230 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R231 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R233 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R271 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(RV777D)
R271 1-216-864-11 SHORT CHIP 0 (RV888D/RV999D)
R301 1-216-841-11 METAL CHIP 47K 5% 1/10W
(RV888D/RV999D)
R302 1-216-817-11 METAL CHIP 470 5% 1/10W
(RV888D/RV999D)
R303 1-216-833-11 METAL CHIP 10K 5% 1/10W
(RV888D/RV999D)
R304 1-216-833-11 METAL CHIP 10K 5% 1/10W
(RV888D/RV999D)
R305 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(RV888D/RV999D)
R306 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(RV888D/RV999D)
R307 1-216-841-11 METAL CHIP 47K 5% 1/10W
(RV888D/RV999D)
R309 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R310 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R311 1-216-841-11 METAL CHIP 47K 5% 1/10W
R312 1-216-857-11 METAL CHIP 1M 5% 1/10W
(RV888D/RV999D)
R313 1-216-833-11 METAL CHIP 10K 5% 1/10W
(RV888D/RV999D)
Ref. No. Part No. Description Remark
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
