HCD-RV777D/RV888D/RV999D
3-7. BACK PANEL SECTION
3-6. JACK BOARD
1 two screws
(+BVTP 2.6 × 8)
4 shield plate
6 JACK board
5 two mic knobs
2 screw
(+BVTP 2.6 × 8)
3 screw
(+BVTP 2.6 × 8)
qs back panel section
5 four screws
(+BVTT 3
× 6)
6 screw
(+BVTP 3
× 10)
9 two screws
(+BVTT 3
× 6)
8 two screws
(+BVTP 3
× 10)
7 two screws
(+BVTP 3
× 10
)
qa CN704
0
1
CN903
2 CN901
3 CN902
4 CN102
