HCD-RV777D/RV888D/RV999D
3-3. FRONT PANEL SECTION, DVD BLOCK SECTION
9 CN605
8 CN706
7 CN503
0 connector
qa connector
2 screw
(+BVTT 3
× 6)
5 screw
(+BVTP 3
× 8)
4 screw
(+BVTP 3
× 8)
3 screw
(+BVTT 3
× 6)
6
two lugs
lug
1 three screws (+BVTT 3 × 6)
qf three screws
(+BVTT 3
× 6)
qd three screws
(+BVTT 3
× 10)
qs two screws
(+BVTT 3
× 10)
qg
qj
CN301
wa CN902
qh CN804
qk CN543
ql CN543
w; DVD block section
ws front panel section
