8
HCD-RV777D/RV888D/RV999D
1-4. SERVICE POSITION OF FRONT AMP BOARD
1-3. SERVICE POSITION OF TCM
tape mechanis
FRONT AMP board
insulating plate
HP board
Note1: For sounding,
remove the HP board
from the front panel and connect it.
Note2: Connect the ground (3 places)
to the chassis of the main body.
