HCD-RV777D/RV888D/RV999D
R875 1-216-809-11 METAL CHIP 100 5% 1/10W
R885 1-216-809-11 METAL CHIP 100 5% 1/10W
R886 1-216-809-11 METAL CHIP 100 5% 1/10W
R887 1-216-821-11 METAL CHIP 1K 5% 1/10W
R888 1-216-809-11 METAL CHIP 100 5% 1/10W
R893 1-216-819-11 METAL CHIP 680 5% 1/10W
(RV777D)
R893 1-216-821-11 METAL CHIP 1K 5% 1/10W
(RV888D)
R893 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(RV999D)
R894 1-216-815-11 METAL CHIP 330 5% 1/10W
(E3,E15)
R894 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EA)
R894 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(AUS)
R894 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(E51,AR,MX)
R894 1-216-864-11 SHORT CHIP 0 (PH,SP,MY)
R895 1-216-809-11 METAL CHIP 100 5% 1/10W
R896 1-216-809-11 METAL CHIP 100 5% 1/10W
R897 1-216-809-11 METAL CHIP 100 5% 1/10W
R899 1-216-809-11 METAL CHIP 100 5% 1/10W
R900 1-216-809-11 METAL CHIP 100 5% 1/10W
R901 1-216-833-11 METAL CHIP 10K 5% 1/10W
R902 1-216-809-11 METAL CHIP 100 5% 1/10W
R929 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R930 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R947 1-216-833-11 METAL CHIP 10K 5% 1/10W
R948 1-216-833-11 METAL CHIP 10K 5% 1/10W
R972 1-216-833-11 METAL CHIP 10K 5% 1/10W
R973 1-216-833-11 METAL CHIP 10K 5% 1/10W
R974 1-216-833-11 METAL CHIP 10K 5% 1/10W
R975 1-216-833-11 METAL CHIP 10K 5% 1/10W
R993 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R994 1-216-821-11 METAL CHIP 1K 5% 1/10W
(E51,AR,MX)
R994 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(E3,E15,AUS,EA)
< TRANSFORMER >
T601 1-437-220-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X800 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X801 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
*************************************************************
1-687-133-12 MOTOR (LD) BOARD
*****************
*************************************************************
1-687-134-12 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
*************************************************************
Ref. No. Part No. Description Remark
A-4751-844-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-126-382-11 ELECT 100uF 20% 16V
C102 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C106 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C107 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C108 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C109 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C121 1-126-794-11 ELECT 4.7uF 20% 50V
C122 1-126-794-11 ELECT 4.7uF 20% 50V
C125 1-126-382-11 ELECT 100uF 20% 16V
C126 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C160 1-119-943-11 ELECT 47uF 20% 50V
C161 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C206 1-126-382-11 ELECT 100uF 20% 16V
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C333 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C334 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C335 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C336 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C337 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C338 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C339 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C340 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C341 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C342 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C343 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C344 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C345 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN2 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
CN101 1-784-737-11 CONNECTOR, FFC 15P
CN103 1-818-282-11 PIN, CONNECTOR 3P
CN104 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P
< DIODE >
D192 6-500-809-01 LED SELU5223C-STP15 (?/1)
< FERRITE BEAD >
FB101 1-469-869-21 INDUCTOR (EMI FERRITE) (2012)
FB102 1-469-869-21 INDUCTOR (EMI FERRITE) (2012)
< FLUORESCENT INDICATOR >
FL1001 1-518-989-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC101 6-804-223-01 IC uPD780232GC-504-8BT-A
< TRANSISTOR >
Q134 8-729-907-00 TRANSISTOR DTC114EU
Q135 8-729-907-00 TRANSISTOR DTC114EU
Q136 8-729-907-00 TRANSISTOR DTC114EU
Q137 8-729-907-00 TRANSISTOR DTC114EU
Ref. No. Part No. Description Remark
