35
HCD-RV777D/RV888D/RV999D
2. Turn the adjustment screw and check output peaks. If the peaks
do not match for L-CH and R-CH, turn the adjustment screw
so that outputs match within 1dB of peak.
3. Mode: Playback
4. After the adjustments, apply suitable locking compound to the
pats adjusted.
screw
position
L-CH
peak
within
1dB
output
level
L-CH
peak
R-CH
peak
within
1dB
screw
position
R-CH
peak
MAIN
board
IC101
test tape
P-4-A063
(6.3 kHz, –10 dB)
pin 37
oscilloscop
L-CH
R-CH
V
H
waveform of oscilloscope
in phase 45
°
90
°
135
°
180
°
good
wrong
pin 38
pin 28
L
R
reverse
forward
Adjustment Location: Playback Head (Deck A).
Record/Playback/Erase Head (Deck B).
