Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONT COMCONNECTOR
* 1-658-575-11 CONNECTOR BOARD
****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* A-4407-304-A CONT COM BOARD, COMPLETE
*************************
< CAPACITOR >
C627 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C628 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C629 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C630 1-164-232-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
* CN608 1-568-862-11 SOCKET, CONNECTOR 19P
< DIODE >
D610 8-719-063-93 DIODE SLR325VC-N-T32 (ENTER/NEXT)
D612 8-719-057-97 DIODE SEL5923A-TP15 (GROOVE)
D613 8-719-063-93 DIODE SLR325VC-N-T32 (JOG)
D614 8-719-064-65 DIODE SELU5723C-TP15 (DJ MIX)
D615 8-719-064-65 DIODE SELU5723C-TP15 (DJ MIX)
D616 8-719-063-93 DIODE SLR325VC-N-T32 (NON-STOP)
D617 8-719-063-93 DIODE SLR325VC-N-T32 (– 0)
D618 8-719-063-93 DIODE SLR325VC-N-T32 (+ ))
D801 8-719-057-97 DIODE SEL5923A-TP15 (ON/OFF)
D802 8-719-057-97 DIODE SEL5923A-TP15 (JAM)
D803 8-719-056-13 DIODE SML79423C-TP15 (AUTO BPM)
< TRANSISTOR >
Q604 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q854 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q855 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R637 1-216-033-00 METAL CHIP 220 5% 1/10W
R638 1-216-035-00 METAL CHIP 270 5% 1/10W
R639 1-216-039-00 METAL CHIP 390 5% 1/10W
R640 1-216-041-00 METAL CHIP 470 5% 1/10W
R641 1-216-045-00 METAL CHIP 680 5% 1/10W
R642 1-216-047-91 RES,CHIP 820 5% 1/10W
R643 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R666 1-216-037-00 METAL CHIP 330 5% 1/10W
R667 1-216-029-00 METAL CHIP 150 5% 1/10W
R668 1-216-027-00 METAL CHIP 120 5% 1/10W
R669 1-216-019-00 METAL CHIP 56 5% 1/10W
R670 1-216-037-00 METAL CHIP 330 5% 1/10W
R671 1-216-031-00 METAL CHIP 180 5% 1/10W
R811 1-216-029-00 METAL CHIP 150 5% 1/10W
R812 1-216-029-00 METAL CHIP 150 5% 1/10W
R813 1-216-029-00 METAL CHIP 150 5% 1/10W
R814 1-216-029-00 METAL CHIP 150 5% 1/10W
R821 1-216-033-00 METAL CHIP 220 5% 1/10W
R822 1-216-035-00 METAL CHIP 270 5% 1/10W
R823 1-216-039-00 METAL CHIP 390 5% 1/10W
R831 1-216-033-00 METAL CHIP 220 5% 1/10W
R832 1-216-035-00 METAL CHIP 270 5% 1/10W
R833 1-216-039-00 METAL CHIP 390 5% 1/10W
< SWITCH >
S601 1-473-534-11 ENCODER, ROTARY (JOG)
S602 1-473-392-11 ENCODER, ROTARY (VOLUME)
S617 1-762-875-21 SWITCH, KEYBOARD (LOOP)
S618 1-762-875-21 SWITCH, KEYBOARD (FLASH)
S619 1-762-875-21 SWITCH, KEYBOARD (NON-STOP)
S621 1-762-875-21 SWITCH, KEYBOARD (– 0)
S622 1-762-875-21 SWITCH, KEYBOARD (ENTER/NEXT)
S623 1-762-875-21 SWITCH, KEYBOARD (+ ))
S624 1-762-875-21 SWITCH, KEYBOARD (DBFB)
S625 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S801 1-762-875-21 SWITCH, KEYBOARD (PAD-B)
S802 1-762-875-21 SWITCH, KEYBOARD (AUTO BPM)
S803 1-762-875-21 SWITCH, KEYBOARD (JAM-BEAT)
S804 1-762-875-21 SWITCH, KEYBOARD (BEAT LEVEL)
S805 1-762-875-21 SWITCH, KEYBOARD (PAD-A)
S806 1-762-875-21 SWITCH, KEYBOARD (ON/OFF-BEAT)
S807 1-762-875-21 SWITCH, KEYBOARD (SELECT-BEAT)
S808 1-762-875-21 SWITCH, KEYBOARD (SPEED-BEAT)
**************************************************************
* 1-668-269-11 DECO BOARD
**********
< DIODE >
D640 8-719-063-93 DIODE SLR325VC-N-T32 (CENTER)
D641 8-719-032-86 DIODE SEL5420E (LEFT)
D642 8-719-032-86 DIODE SEL5420E (LEFT)
D643 8-719-032-86 DIODE SEL5420E (LEFT)
D644 8-719-033-06 DIODE SEL5920A (CENTER)
D655 8-719-033-06 DIODE SEL5920A (RIGHT)
D656 8-719-033-06 DIODE SEL5920A (RIGHT)
< TRANSISTOR >
Q856 8-729-027-60 TRANSISTOR DTC144TKA-T146
Q857 8-729-027-60 TRANSISTOR DTC144TKA-T146
< RESISTOR >
R706 1-216-019-00 METAL CHIP 56 5% 1/10W
R707 1-216-019-00 METAL CHIP 56 5% 1/10W
R708 1-216-041-00 METAL CHIP 470 5% 1/10W
