– 111 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R709 1-216-027-00 METAL CHIP 120 5% 1/10W
R710 1-216-027-00 METAL CHIP 120 5% 1/10W
**************************************************************
* 1-668-271-11 HP BOARD
********
< CAPACITOR >
C790 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C791 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C792 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN752 1-506-469-11 PIN, CONNECTOR 4P
< GROUND PLATE >
* EP751 1-537-738-21 TERMINAL, EARTH
< JACK >
J755 1-784-224-11 JACK (LARGE TYPE)(PHONES)
**************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-128-124-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119
D1002 8-719-911-19 DIODE 1SS119
< CONNECTOR >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
Q1001 8-729-900-65 TRANSISTOR DTA144ES
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-205-11 SWITCH, LEAF (A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1008 1-771-205-11 SWITCH, LEAF (B 120/70)
S1009 1-771-205-11 SWITCH, LEAF (REC B)
************************************************************
* A-4405-131-A MAIN BOARD, COMPLETE
********************
(GRX8:E3,SP,MY,HK,TW,EA3)
* A-4405-146-A MAIN BOARD, COMPLETE
********************
(RX88/RX99:AEP,UK,G)
* A-4407-252-A MAIN BOARD, COMPLETE (GRX8:E2,MX/R800)
********************
* A-4407-322-A MAIN BOARD, COMPLETE (RX99:EE,CIS)
**********************************
* A-4407-723-A MAIN BOARD, COMPLETE (GRX8:AUS)
********************
* A-4407-749-A MAIN BOARD, COMPLETE (GRX8:EA4,TH)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C102 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C103 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C111 1-137-195-11 FILM 0.56uF 5% 50V
C112 1-163-986-00 CERAMIC CHIP 0.027uF 10% 25V
C113 1-136-167-00 FILM 0.15uF 5% 50V
C114 1-163-018-00 CERAMIC CHIP 0.0056uF 5% 50V
C115 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C116 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C117 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C118 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C119 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C120 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C123 1-136-169-00 FILM 0.22uF 5% 50V
C124 1-136-169-00 FILM 0.22uF 5% 50V
C125 1-126-964-11 ELECT 10uF 20% 50V
LEAF SW MAINHPDECO
