119
HCD-SC5/SC6/SC8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C340 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP,UK,RU)
C342 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(AEP,UK,RU)
C472 1-126-933-11 ELECT 100uF 20.00% 16V
C608 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(EXCEPT AEP,UK,RU)
C608 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
(AEP,UK,RU)
C609 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(EXCEPT AEP,UK,RU)
C609 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
(AEP,UK,RU)
< CONNECTOR >
CN201 1-816-955-11 CONNECTOR, FFC/FPC 11P
CN202 1-779-566-21 CONNECTOR,FFC(LIF(NON-ZIF))29P
CN203 1-779-552-21 CONNECTOR,FFC(LIF(NON-ZIF))15P
* CN205 1-506-992-11 PIN, CONNECTOR (PC BOARD) 10P
(AEP,UK,RU)
< DIODE >
D103 8-719-988-61 DIODE 1SS355TE-17 (AEP,UK,RU)
D201 8-719-069-54 DIODE UDZ-TE-17-5.1B (AEP,UK,RU)
D202 8-719-404-50 DIODE MA111-TX
D203 8-719-404-50 DIODE MA111-TX
D206 8-719-404-50 DIODE MA111-TX
< IC >
IC201 8-759-557-36 IC BU1924F-E2 (AEP,UK,RU)
IC202 8-759-385-76 IC MC14052 BDR2
IC204 6-600-013-01 IC TORX179L (0PTICAL DIGITAL IN)
IC206 6-702-334-01 IC MM1510XNRE
IC207 8-759-696-10 IC NJM2235V(TE2)
IC208 6-702-335-01 IC MM1568AJBE
IC209 8-759-284-49 IC NJM2285V-TE2
< JACK >
J202 1-694-920-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT) (EXCEPT AEP,UK,RU)
J205 1-816-605-11 JACK, PIN 6P (VIDEO 1)
J206 1-764-592-11 JACK 3P (VIDEO 2) (AEP,UK,RU)
J206 1-816-604-11 JACK, PIN 6P (VIDEO 2) (EXCEPT AEP,UK,RU)
< COIL >
L202 1-469-525-91 INDUCTOR 10uH
L205 1-469-525-91 INDUCTOR 10uH
L206 1-469-525-91 INDUCTOR 10uH
L207 1-469-525-91 INDUCTOR 10uH
L209 1-469-525-91 INDUCTOR 10uH
L210 1-216-864-11 METAL CHIP 0 5% 1/16W
L211 1-216-864-11 METAL CHIP 0 5% 1/16W
L212 1-216-864-11 METAL CHIP 0 5% 1/16W
L213 1-216-864-11 METAL CHIP 0 5% 1/16W
L214 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q137 8-729-900-53 TRANSISTOR DTC114EKA-T146
(AEP,UK,RU)
Q138 8-729-027-23 TRANSISTOR DTA114EKA-T146
(AEP,UK,RU)
Q139 8-729-900-53 TRANSISTOR DTC114EKA-T146
(AEP,UK,RU)
Q140 8-729-027-23 TRANSISTOR DTA114EKA-T146
(AEP,UK,RU)
Q141 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
(AEP,UK,RU)
Q142 8-729-900-53 TRANSISTOR DTC114EKA-T146
(AEP,UK,RU)
Q201 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
(AEP,UK,RU)
Q205 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q206 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q207 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q208 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q210 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q214 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q220 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q221 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q222 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q223 8-729-901-00 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R178 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(AEP,UK,RU)
R181 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(AEP,UK,RU)
R182 1-216-815-11 METAL CHIP 330 5% 1/16W
(AEP,UK,RU)
R183 1-216-815-11 METAL CHIP 330 5% 1/16W
(AEP,UK,RU)
R184 1-216-815-11 METAL CHIP 330 5% 1/16W
(AEP,UK,RU)
R185 1-216-815-11 METAL CHIP 330 5% 1/16W
(AEP,UK,RU)
R186 1-216-821-11 METAL CHIP 1K 5% 1/16W
(AEP,UK,RU)
R187 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(AEP,UK,RU)
R188 1-216-837-11 METAL CHIP 22K 5% 1/16W
(AEP,UK,RU)
R190 1-216-849-11 METAL CHIP 220K 5% 1/16W
(AEP,UK,RU)
R191 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AEP,UK,RU)
R201 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(AEP,UK,RU)
R202 1-216-821-11 METAL CHIP 1K 5% 1/16W
(AEP,UK,RU)
R203 1-216-843-11 METAL CHIP 68K 5% 1/16W
(AEP,UK,RU)
R204 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AEP,UK,RU)
R205 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AEP,UK,RU)
R206 1-216-853-11 METAL CHIP 470K 5% 1/16W
(AEP,UK,RU)
R207 1-216-815-11 METAL CHIP 330 5% 1/16W
(AEP,UK,RU)
R208 1-216-813-11 METAL CHIP 220 5% 1/16W
R209 1-216-813-11 METAL CHIP 220 5% 1/16W
I/O
To Next Page
