Sony HCD-SC8 - Page 120

120
HCD-SC5/SC6/SC8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R210 1-216-813-11 METAL CHIP 220 5% 1/16W
R211 1-216-813-11 METAL CHIP 220 5% 1/16W
R212 1-216-813-11 METAL CHIP 220 5% 1/16W
R213 1-216-841-11 METAL CHIP 47K 5% 1/16W
R214 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R215 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R216 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R217 1-216-839-11 METAL CHIP 33K 5% 1/16W
R218 1-216-833-11 METAL CHIP 10K 5% 1/16W
R219 1-216-809-11 METAL CHIP 100 5% 1/16W
R220 1-216-839-11 METAL CHIP 33K 5% 1/16W
(AEP,UK,RU)
R220 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT AEP,UK,RU)
R221 1-216-839-11 METAL CHIP 33K 5% 1/16W
(AEP,UK,RU)
R221 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT AEP,UK,RU)
R222 1-216-839-11 METAL CHIP 33K 5% 1/16W
R223 1-216-833-11 METAL CHIP 10K 5% 1/16W
R224 1-216-809-11 METAL CHIP 100 5% 1/16W
R225 1-216-839-11 METAL CHIP 33K 5% 1/16W
R226 1-216-839-11 METAL CHIP 33K 5% 1/16W
R227 1-216-821-11 METAL CHIP 1K 5% 1/16W
R228 1-216-821-11 METAL CHIP 1K 5% 1/16W
R229 1-216-845-11 METAL CHIP 100K 5% 1/16W
R230 1-216-845-11 METAL CHIP 100K 5% 1/16W
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R233 1-216-833-11 METAL CHIP 10K 5% 1/16W
R235 1-216-841-11 METAL CHIP 47K 5% 1/16W
R236 1-216-833-11 METAL CHIP 10K 5% 1/16W
R237 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R238 1-216-833-11 METAL CHIP 10K 5% 1/16W
R241 1-216-841-11 METAL CHIP 47K 5% 1/16W
R242 1-216-833-11 METAL CHIP 10K 5% 1/16W
R243 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R244 1-216-833-11 METAL CHIP 10K 5% 1/16W
R245 1-216-864-11 METAL CHIP 0 5% 1/16W
R246 1-216-841-11 METAL CHIP 47K 5% 1/16W
R247 1-216-833-11 METAL CHIP 10K 5% 1/16W
R249 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R250 1-216-833-11 METAL CHIP 10K 5% 1/16W
R251 1-218-285-11 METAL CHIP 75 5% 1/10W
R252 1-216-833-11 METAL CHIP 10K 5% 1/16W
R253 1-216-841-11 METAL CHIP 47K 5% 1/16W
R254 1-218-285-11 METAL CHIP 75 5% 1/10W
R255 1-216-809-11 METAL CHIP 100 5% 1/16W
R256 1-216-833-11 METAL CHIP 10K 5% 1/16W
R259 1-218-285-11 METAL CHIP 75 5% 1/10W
R265 1-216-833-11 METAL CHIP 10K 5% 1/16W
R266 1-216-833-11 METAL CHIP 10K 5% 1/16W
R267 1-218-285-11 METAL CHIP 75 5% 1/10W
R268 1-218-285-11 METAL CHIP 75 5% 1/10W
R269 1-218-285-11 METAL CHIP 75 5% 1/10W
R270 1-218-285-11 METAL CHIP 75 5% 1/10W
R271 1-216-864-11 METAL CHIP 0 5% 1/16W
R273 1-218-285-11 METAL CHIP 75 5% 1/10W
R278 1-216-833-11 METAL CHIP 10K 5% 1/16W
R286 1-216-833-11 METAL CHIP 10K 5% 1/16W
R290 1-216-853-11 METAL CHIP 470K 5% 1/16W
R291 1-216-853-11 METAL CHIP 470K 5% 1/16W
R292 1-216-821-11 METAL CHIP 1K 5% 1/16W
R293 1-216-821-11 METAL CHIP 1K 5% 1/16W
R294 1-216-814-11 METAL CHIP 270 5% 1/16W
(AEP,UK,RU)
R294 1-216-815-11 METAL CHIP 330 5% 1/16W
(EXCEPT AEP,UK,RU)
R295 1-216-814-11 METAL CHIP 270 5% 1/16W
(AEP,UK,RU)
R295 1-216-815-11 METAL CHIP 330 5% 1/16W
(EXCEPT AEP,UK,RU)
R296 1-216-833-11 METAL CHIP 10K 5% 1/16W
(AEP,UK,RU)
R297 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT AEP,UK,RU)
R344 1-216-833-11 METAL CHIP 10K 5% 1/16W
(AEP,UK,RU)
R346 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AEP,UK,RU)
R347 1-216-833-11 METAL CHIP 10K 5% 1/16W
(AEP,UK,RU)
R349 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
(AEP,UK,RU)
R350 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
(AEP,UK,RU)
R352 1-216-833-11 METAL CHIP 10K 5% 1/16W
(AEP,UK,RU)
R353 1-216-841-11 METAL CHIP 47K 5% 1/16W
(AEP,UK,RU)
R360 1-216-833-11 METAL CHIP 10K 5% 1/16W
(AEP,UK,RU)
< SWITCH >
S801 1-771-692-11 SWITCH, SLIDE (SCAN SELECT)
(EXCEPT AEP,UK,RU)
< VIBRATOR >
X201 1-579-900-21 VIBRATOR, CRYSTAL 4.332MHz (AEP,UK,RU)
************************************************************
A-4747-662-A LF BOARD, COMPLETE
(SC5:AEP,UK,RU,SP,EA,HK,KR/SC6:RU,SP,EA,KR,AUS/
SC8:RU,SP,EA,HK,KR,AUS)
******************
A-4749-311-A LF BOARD, COMPLETE (SC8:MX)
******************
A-4749-715-A LF BOARD, COMPLETE (SC5:E32/SC8:E32)
******************
A-4749-846-A LF BOARD, COMPLETE (SC5:TW/SC8:TW)
******************
< CAPACITOR >
0 C903 1-104-705-11 MYLAR 0.1uF 20.00% 250V
< CONNECTOR >
CN900 1-564-321-00 PIN, CONNECTOR(3.96mm PITCH)2P
* CN901 1-564-321-21 PIN, CONNECTOR(3.96mm PITCH)2P
I/O LF
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
