121
HCD-SC5/SC6/SC8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< LINE FILTER >
0 LF901 1-456-081-11 COIL, LINE FILTER (EXCEPT E32,MX,TW)
0 LF901 1-456-082-11 COIL, LINE FILTER (E32,MX,TW)
< RESISTOR >
0 R930 1-219-237-11 SOLID 3.3M 20% 1/2W
(EXCEPT MX,TW)
************************************************************
A-4748-367-A POWER BOARD, COMPLETE
(SC5:AEP,UK,RU,SP,EA,HK,KR/SC6:RU,SP,EA,KR,AUS/
SC8:RU,SP,EA,HK,KR,AUS)
**********************
A-4749-310-A POWER BOARD, COMPLETE (SC8:MX)
**********************
A-4749-714-A POWER BOARD, COMPLETE
(SC5:E32/SC8:E32)
**********************
A-4749-845-A POWER BOARD, COMPLETE (SC5:TW/SC8:TW)
**********************
7-685-646-79 SCREW+BVTP 3X8 TYPE2 N-S
< CAPACITOR >
0 C901 1-126-963-11 ELECT 4.7uF 20.00% 50V
0 C904 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
0 C905 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C906 1-126-967-11 ELECT 47uF 20.00% 50V
0 C907 1-104-705-11 MYLAR 0.1uF 20.00% 250V
0 C912 1-100-446-11 ELECT 220uF 20% 450V
(EXCEPT E32,MX,TW)
0 C912 1-100-192-11 ELECT 1000uF 20% 200V
(MX,TW)
0 C912 1-165-911-21 ELECT 390uF 20% 450V
(E32)
0 C913 1-117-452-11 FILM 3300PF 5.00% 630V
(EXCEPT MX,TW)
0 C913 1-136-203-11 FILM 10000PF 5.00% 630V
(MX,TW)
0 C914 1-126-947-11 ELECT 47uF 20.00% 35V
C915 1-164-156-11 CERAMIC CHIP 0.1uF 25V
0 C916 1-104-332-11 CERAMIC 470PF 10.00% 2KV
(EXCEPT MX,TW)
0 C916 1-117-824-11 FILM 2200PF 3.00% 1.5KV
(MX,TW)
C917 1-113-907-51 CERAMIC 0.0022uF 99% 250V
(MX,TW)
C917 1-117-699-11 CERAMIC 0.001uF 99% 250V
(EXCEPT MX,TW)
C918 1-165-319-11 CERAMIC CHIP 0.1uF 50V
0 C919 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT MX,TW)
0 C919 1-164-315-11 CERAMIC CHIP 470PF 2.00% 50V
(MX,TW)
C920 1-117-454-11 FILM 4700PF 5.00% 630V
(EXCEPT MX,TW)
C920 1-137-699-11 FILM 2700PF 5% 630V
(MX,TW)
C921 1-107-898-11 ELECT 2200uF 20.00% 35V
C922 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C923 1-107-898-11 ELECT 2200uF 20.00% 35V
C924 1-107-898-11 ELECT 2200uF 20.00% 35V
C925 1-126-960-11 ELECT 1uF 20.00% 50V
C926 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C927 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C928 1-126-952-11 ELECT 1000uF 20.00% 35V
C929 1-104-665-11 ELECT 100uF 20.00% 10V
C930 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C931 1-165-723-21 ELECT 1000uF 20% 10V
C932 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C933 1-165-723-21 ELECT 1000uF 20% 10V
C934 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C935 1-128-950-21 ELECT 1000uF 20% 16V
C936 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C937 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
0 C938 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
0 C939 1-113-907-51 CERAMIC 0.0022uF 99% 250V
(E32,MX,TW)
0 C939 1-117-699-11 CERAMIC 0.001uF 99% 250V
(EXCEPT E32,MX,TW)
C941 1-126-947-11 ELECT 47uF 20.00% 16V
< CONNECTOR >
* CN902 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN903 1-506-996-11 PIN, CONNECTOR (PC BOARD) 14P
CN904 1-565-731-11 PLUG, CONNECTOR (2.5mm) 5P
< DIODE >
0 D902 8-719-022-92 DIODE RBV-604 (MX,TW)
0 D902 8-719-312-05 DIODE RBV-606 (EXCEPT MX,TW)
D904 8-719-109-97 DIODE MTZJ-T-77-6.8B
0 D905 8-719-991-33 DIODE 1SS133T-77
0 D906 8-719-200-91 DIODE 11EQS10-TA1
0 D907 8-719-991-33 DIODE 1SS133T-77
0 D908 6-500-241-01 DIODE SARS03
D911 8-719-313-14 DIODE FML-22S
D912 8-719-109-93 DIODE MTZJ-T-77-6.2B
D913 8-719-404-50 DIODE MA111-TX
D914 8-719-312-08 DIODE FMB-G16L
D915 8-719-200-82 DIODE 11ES2-NTA1B
D916 8-719-312-08 DIODE FMB-G16L
D917 8-719-200-82 DIODE 11ES2-NTA1B
0 D919 8-719-084-21 DIODE 10E6N-TA1B2
0 D920 8-719-084-21 DIODE 10E6N-TA1B2
D921 8-719-975-85 DIODE 21DQ04N-TA2
D922 8-719-083-60 DIODE UDZSTE-174.7B
0 D931 8-719-110-53 DIODE MTZJ-T-77-20B
0 D932 8-719-924-13 DIODE MTZJ-T-77-22B
0 D933 8-719-200-91 DIODE 11EQS10-TA1
D990 8-719-404-50 DIODE MA111-TX
< GROUND TERMINAL BOARD >
EB902 1-537-770-21 TERMINAL BOARD, GROUND
LF POWER
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
