HCD-SC5/SC6/SC8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< FUSE HOLDER >
FH901 1-533-313-11 FUSE HOLDER
FH902 1-533-313-11 FUSE HOLDER
< IC >
0 IC901 6-703-098-01 IC STR-F6267D (EXCEPT MX,TW)
0 IC901 6-702-338-01 IC STR-F6238S (MX,TW)
IC902 6-700-388-01 IC SE-B2
IC903 8-759-474-09 IC SI-8050S-LF1101
IC904 8-759-332-29 IC M51945BL
IC905 8-759-450-47 IC BA05T
IC906 6-700-813-01 IC SI-8033JF
IC908 6-701-021-01 IC SI-8120JF
IC909 8-759-510-71 IC BA10358F-E2
< COIL >
L901 1-424-860-11 INDUCTOR 10uH
L902 1-456-183-11 INDUCTOR 150uH
L903 1-456-213-11 INDUCTOR 0.1MH
L904 1-456-419-11 INDUCTOR 120uH
L905 1-414-398-11 INDUCTOR 10uH
L906 1-414-398-11 INDUCTOR 10uH
L907 1-414-398-11 INDUCTOR 10uH
L908 1-414-398-11 INDUCTOR 10uH
L909 1-414-398-11 INDUCTOR 10uH
L910 1-414-398-11 INDUCTOR 10uH
L911 1-414-398-11 INDUCTOR 10uH
L912 1-414-398-11 INDUCTOR 10uH
L913 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0 LF902 1-456-081-11 COIL, LINE FILTER (EXCEPT E32,MX,TW)
0 LF902 1-456-082-11 COIL, LINE FILTER (E32,MX,TW)
< IC >
0 PC901 8-749-019-04 IC TLP421
0 PC902 8-749-019-04 IC TLP421
< TRANSISTOR >
Q901 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q902 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q903 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q904 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
0 Q905 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q906 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q907 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q912 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q914 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q990 8-729-030-19 TRANSISTOR 2SB1640(TP)
Q991 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q992 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
< RESISTOR >
0 R901 1-216-813-11 METAL CHIP 220 5% 1/16W
0 R902 1-245-392-51 METAL OXIDE 0.15 5% 1W
(MX,TW)
0 R903 1-245-392-51 METAL OXIDE 0.15 5% 1W
0 R904 1-216-341-11 METAL OXIDE 0.22 5% 1W
0 R905 1-215-926-00 METAL OXIDE 33K 5% 3W
(MX,TW)
0 R905 1-215-928-11 METAL OXIDE 68K 5% 3W
(EXCEPT MX,TW)
R906 1-216-833-11 METAL CHIP 10K 5% 1/16W
0 R907 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
0 R908 1-215-928-11 METAL OXIDE 68K 5% 3W
(EXCEPT MX,TW)
0 R909 1-215-902-11 METAL OXIDE 47K 5% 2W
(EXCEPT MX,TW)
R910 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
0 R911 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
0 R912 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
0 R913 1-249-385-11 CARBON 2.2 5% 1/6W F
R914 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R915 1-216-812-11 METAL CHIP 180 5% 1/16W
R916 1-249-417-11 CARBON 1K 5% 1/4W F
(EXCEPT MX,TW)
R916 1-249-418-11 CARBON 1.2K 5% 1/4W F
(MX,TW)
R917 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R918 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R919 1-216-833-11 METAL CHIP 10K 5% 1/16W
R920 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R921 1-216-837-11 METAL CHIP 22K 5% 1/16W
R922 1-218-866-11 METAL CHIP 6.2K 5% 1/10W
R923 1-216-833-11 METAL CHIP 10K 5% 1/16W
R924 1-216-818-11 METAL CHIP 560 5% 1/16W
R925 1-216-812-11 METAL CHIP 180 5% 1/16W
R926 1-216-845-11 METAL CHIP 100K 5% 1/16W
R927 1-216-821-11 METAL CHIP 1K 5% 1/16W
R928 1-216-837-11 METAL CHIP 22K 5% 1/16W
R929 1-216-805-11 METAL CHIP 47 5% 1/16W
(EXCEPT MX,TW)
R931 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R933 1-216-837-11 METAL CHIP 22K 5% 1/16W
0 R934 1-215-904-11 METAL OXIDE 100K 5% 2W
(EXCEPT MX,TW)
R935 1-216-845-11 METAL CHIP 100K 5% 1/16W
0 R936 1-216-847-11 METAL CHIP 150K 5% 1/16W
R937 1-216-821-11 METAL CHIP 1K 5% 1/16W
R938 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R940 1-216-835-11 METAL CHIP 15K 5% 1/16W
R941 1-216-833-11 METAL CHIP 10K 5% 1/16W
R942 1-216-833-11 METAL CHIP 10K 5% 1/16W
R943 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R944 1-215-902-11 METAL OXIDE 47K 5% 2W
(MX,TW)
R944 1-215-904-11 METAL OXIDE 100K 5% 2W
(EXCEPT MX,TW)
R945 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R946 1-216-812-11 METAL CHIP 180 5% 1/16W
R947 1-216-815-11 METAL CHIP 330 5% 1/16W
R948 1-216-833-11 METAL CHIP 10K 5% 1/16W
R949 1-216-833-11 METAL CHIP 10K 5% 1/16W
R950 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
POWER
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
