Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE33/SHAKE77
109
C724 1-124-779-00 ELECT CHIP 10uF 20% 16V
C726 1-128-392-11 ELECT CHIP 470uF 20% 6.3V
C737 1-124-779-00 ELECT CHIP 10uF 20% 16V
C738 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C740 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C741 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C742 1-124-779-00 ELECT CHIP 10uF 20% 16V
C743 1-124-779-00 ELECT CHIP 10uF 20% 16V
C744 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C745 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C746 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
*
C747 1-118-407-11 CERAMIC CHIP 470PF 10% 50V
C748 1-124-779-00 ELECT CHIP 10uF 20% 16V
C749 1-124-779-00 ELECT CHIP 10uF 20% 16V
C751 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C752 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C753 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C754 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C756 1-124-779-00 ELECT CHIP 10uF 20% 16V
*
C757 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C758 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
*
C759 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C761 1-124-779-00 ELECT CHIP 10uF 20% 16V
C763 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C764 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
*
C765 1-118-407-11 CERAMIC CHIP 470PF 10% 50V
C766 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C767 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C913 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
*
C914 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C917 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
< CONNECTOR >
CN001 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN101 1-774-731-21 PIN, CONNECTOR (PC BOARD) 5P
(FOR SERVICE USE)
CN102 1-820-825-81 CONNECTOR, FFC/FPC (LIF) 10P
CN105 1-820-384-31 CONNECTOR, FFC/FPC (LIF) 8P
CN106 1-779-806-21 CONNECTOR 8P
CN107 1-778-384-51 CONNECTOR, FFC/FPC 16P
(FOR SERVICE USE)
CN109 1-820-121-51 CONNECTOR, FFC/FPC 23P
CN111 1-820-119-51 CONNECTOR, FFC/FPC 21P
CN301 1-691-550-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
CN302 1-843-557-11 FFC ST CONNECTOR (NON-ZIF) 24P
CN303 1-794-362-51 CONNECTOR, FFC/FPC 5P
CN304 1-573-806-21 PIN, CONNECTOR (1.5MM) (SMD) 6P
CN305 1-573-806-21 PIN, CONNECTOR (1.5MM) (SMD) 6P
CN401 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN451 1-770-468-21 PIN, CONNECTOR (PC BOARD) 10P
*
CN501 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER L)
*
CN502 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER R)
CN601 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P (SHAKE77)
CN851 1-820-112-51 CONNECTOR, FFC/FPC 9P
< DIODE >
D003 6-500-400-01 DIODE BAV99-215
D005 6-500-400-01 DIODE BAV99-215
D102 6-502-961-01 DI DA2J10100L
*
D104 6-503-578-01 DI RB520SM-30T2R
*
D105 6-503-578-01 DI RB520SM-30T2R
*
D106 6-503-578-01 DI RB520SM-30T2R
*
D107 6-503-578-01 DI RB520SM-30T2R
*
D108 6-503-578-01 DI RB520SM-30T2R
*
D109 6-503-578-01 DI RB520SM-30T2R
*
D110 6-503-578-01 DI RB520SM-30T2R
*
D111 6-503-578-01 DI RB520SM-30T2R
*
D112 6-503-578-01 DI RB520SM-30T2R
*
D113 6-503-578-01 DI RB520SM-30T2R
*
D114 6-503-578-01 DI RB520SM-30T2R
*
D115 6-503-578-01 DI RB520SM-30T2R
*
D116 6-503-578-01 DI RB520SM-30T2R
*
D117 6-503-578-01 DI RB520SM-30T2R
*
D118 6-503-578-01 DI RB520SM-30T2R
*
D119 6-503-578-01 DI RB520SM-30T2R
D401 8-719-069-29 DIODE RB520S-30FJTE61
D402 8-719-069-29 DIODE RB520S-30FJTE61
D571 6-502-961-01 DI DA2J10100L
D572 6-502-961-01 DI DA2J10100L
< FERRITE BEAD >
FB101 1-481-515-11 BEAD, FERRITE (1608)
< IC >
IC001 (Not supplied) IC TPS542941PWPR
IC002 (Not supplied) IC TPS542941PWPR
IC004 6-715-078-01 IC KIA7809AF/API
IC006 6-717-138-01 IC KIA7805AF-RTF/PW
IC101 6-721-336-01 IC R7S7200022CFP
IC102 6-707-866-01 IC TC74VHC126FT (EKJ)
IC103 6-719-856-01 IC BU4229F-TR
IC105 6-718-324-01 IC MFI337S3959
IC106 (Not supplied) IC MX25L3235EM2I-10G
IC301 6-718-440-01 IC CXD90013R
IC302 (Not supplied) IC W25Q16CVSSIG-R
IC303 6-712-033-01 IC MM1701CHBE
IC306 (Not supplied) IC M12L64164A-7TG2Y
IC401 6-720-195-01 IC AM5890S
*
IC451 6-721-151-01 IC GL850G-OGY33
IC452 6-718-580-01 IC BA2903FV-E2
IC502 6-719-142-01 IC TC62D723FNG
IC601 8-759-909-71 IC BA4558F
IC602 8-759-596-39 IC SN74LV4052APWR
IC603 8-759-909-71 IC BA4558F
IC604 6-705-973-01 IC PCM1754DBQR
IC605 8-759-596-39 IC SN74LV4052APWR
IC606 6-710-554-01 IC PCM1808PWR
IC607 8-759-680-48 IC TC7WH157FK
IC609 6-710-554-01 IC PCM1808PWR (SHAKE77)
IC610 6-707-800-01 IC SRC4182
IC611 6-705-973-01 IC PCM1754DBQR
IC612 8-759-909-71 IC BA4558F
IC615 6-705-973-01 IC PCM1754DBQR
IC616 8-759-909-71 IC BA4558F
MOTHERBOARD
Note: IC001, IC002, IC106, IC302 and IC306 on the MOTHER-
BOARD board cannot exchange with single. When these
parts on the MOTHERBOARD board are damaged, ex-
change the entire mounted board.
