HCD-SHAKE33/SHAKE77
30
SECTION 6
DIAGRAMS
• Circuit Boards Location
MS-476 board
4CH DAMP board (SHAKE33)
6CH DAMP board (SHAKE77)
MOTHERBOARD board
TUNER board
REGULATOR, SWITCHING (3H401W)
(SHAKE33)
SWITCHING REGULATOR (SSN-GBR)
(SHAKE77)
FL board
BLUETOOTH module
STR board
MIC board
RC-S801/A (WW)
