91
HCD-SHAKE33/SHAKE77
SECTION 8
ELECTRICAL PARTS LIST
A-1977-136-A 4CH DAMP BOARD, COMPLETE (SHAKE33)
*************************
< CAPACITOR >
C1000 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1003 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1004 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1005 1-126-400-11 ELECT CHIP 22uF 20% 35V
C1006 1-126-400-11 ELECT CHIP 22uF 20% 35V
C1007 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1008 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1010 1-118-291-11 CERAMIC CHIP 100PF 5% 50V
C1011 1-126-400-11 ELECT CHIP 22uF 20% 35V
C1012 1-126-400-11 ELECT CHIP 22uF 20% 35V
C1013 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1014 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1016 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1019 1-128-992-21 ELECT CHIP 47uF 20% 25V
C1020 1-128-992-21 ELECT CHIP 47uF 20% 25V
C1021 1-126-204-11 ELECT CHIP 47uF 20% 16V
C1022 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1023 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C1024 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1025 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1026 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1027 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C1028 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C1112 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1122 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C1125 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1126 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1157 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1160 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1163 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C1164 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1166 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C1167 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1168 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1169 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1170 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1171 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1172 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C1173 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1174 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1175 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1178 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1179 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1180 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1182 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
*
C1183 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1184 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1185 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1186 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1188 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C1190 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
*
C1191 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1192 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1193 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1194 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1196 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1198 1-118-626-11 ELECT 4700uF 20% 71V
C1199 1-118-626-11 ELECT 4700uF 20% 71V
C1202 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1209 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C1210 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1211 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1212 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1213 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1214 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1218 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1219 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1221 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C1223 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1224 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1225 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1226 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C1227 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1228 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1229 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1231 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1232 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1234 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: —, for example:
uA. . : —A. . , uPA. . , —PA. . ,
uPB. . : —PB. . , uPC. . , —PC. . ,
uPD. . : —PD. .
• CAPACITORS
uF: —F
• COILS
uH: —H
• Abbreviation
AUS : Australian model
E2 : 120 V AC area in E model
E51 : Chilean and Peruvian models
MX : Mexican model
4CH DAMP
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
