Sony HCD-SHAKE33 - Back Panel Section

85
HCD-SHAKE33/SHAKE77
#1
#1
#1
#2
#2
#2
#2
#1
#1
not supplied
not
supplied
not supplied
MOTHERBOARD board section
front panel section
51
53
CD MECHANISM
section
(SHAKE77)
#1
not
supplied
not supplied
not supplied
(TUNER board)
52
7-2. BACK PANEL SECTION
0
51 1-855-006-51 DC FAN
52 1-828-309-21 WIRE (FLAT TYPE) (9 CORE)
53 2-677-839-01 +PWH 3X8 (SUMITITE)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note: If wire (fl at type) is replaced, install it after bending
it in the same form as that before replacement.
