Sony HCD-SHAKE33 - 4 CH DAMP Board (SHAKE33), 6 CH DAMP Board (SHAKE77)

HCD-SHAKE33/SHAKE77
14
2-7. 4CH DAMP BOARD (SHAKE33), 6CH DAMP BOARD (SHAKE77)
B
B
D
D
D
E
E
B
qs
qs
‡:LUHVHWWLQJ
front side
SWITCHING REGULATOR (SSN-GBR)
bracket, tunnel
(M7)
‡:LUHVHWWLQJ
front side
REGULATOR, SWITCHING (3H401W)
bracket,
tunnel
(M3)
1 CN1001 (2P)
6 CN1000 (10P)
1 CN1001
(2P)
2 two screws
(+BVTP 3 u 8)
3 two screws
(+BVTP 3 u 8)
3 two screws
(+BVTP 3 u 8)
2 four screws
(+BVTP 3 u 8)
0 six screws
(+BVTP 3 u 8)
qa 6CH DAMP board
qa 4CH DAMP
board
2 two screws
(+BVTP 3 u 8)
4 bracket,
tunnel (M7)
4 bracket,
tunnel (M3)
5 DC fan
5 fan, DC
8 thermal sheet
8 sheet,
thermal
7 three screws
(+PTPWH 2.6 u L
(DIA8.0))
7 three screws
(+PTPWH 2.6 u L
(DIA8.0))
9 heat sink
0 four screws
(+BVTP 3 u 8)
9 heat sink (M3)
qd bracket, heat sink (M7)
qd bracket,
heat sink
C
C
C
(SHAKE77)(SHAKE33)
