Sony HCD-SHAKE33 - Page 115

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE33/SHAKE77
115
MOTHERBOARD
STR
R818 1-218-965-11 METAL CHIP 10K 5% 1/16W
R819 1-218-929-11 METAL CHIP 10 5% 1/16W
R820 1-218-929-11 METAL CHIP 10 5% 1/16W
R821 1-218-929-11 METAL CHIP 10 5% 1/16W
R822 1-218-929-11 METAL CHIP 10 5% 1/16W
R851 1-218-990-81 SHORT CHIP 0
R852 1-218-990-81 SHORT CHIP 0
R853 1-218-990-81 SHORT CHIP 0
R854 1-218-990-81 SHORT CHIP 0
R855 1-218-990-81 SHORT CHIP 0
R856 1-218-990-81 SHORT CHIP 0
R857 1-216-864-11 SHORT CHIP 0
R859 1-216-864-11 SHORT CHIP 0
R906 1-218-973-11 METAL CHIP 47K 5% 1/16W
R907 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R908 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R909 1-218-990-81 SHORT CHIP 0 (SHAKE33)
R910 1-218-990-81 SHORT CHIP 0 (SHAKE77)
R911 1-218-985-11 METAL CHIP 470K 5% 1/16W
R912 1-218-985-11 METAL CHIP 470K 5% 1/16W
R913 1-218-975-11 METAL CHIP 68K 5% 1/16W
R914 1-218-975-11 METAL CHIP 68K 5% 1/16W
R915 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R916 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB301 1-234-370-21 RES, NETWORK 22 (1005X4)
RB302 1-234-370-21 RES, NETWORK 22 (1005X4)
RB303 1-234-370-21 RES, NETWORK 22 (1005X4)
RB304 1-234-370-21 RES, NETWORK 22 (1005X4)
RB305 1-234-370-21 RES, NETWORK 22 (1005X4)
RB306 1-234-370-21 RES, NETWORK 22 (1005X4)
RB307 1-234-370-21 RES, NETWORK 22 (1005X4)
RB308 1-234-370-21 RES, NETWORK 22 (1005X4)
RB309 1-234-370-21 RES, NETWORK 22 (1005X4)
< THERMISTOR >
TH571 1-804-949-11 THERMISTOR, NTC (SMD)
< VIBRATOR >
X101 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768kHz)
X102 1-814-767-11 QUARTZ CRYSTAL UNITS (13.333MHz)
X103 1-814-466-11 QUARTZ CRYSTAL UNITS (12.288MHz)
X301 1-814-023-11 QUARTS CRYSTAL UNIT (27MHz)
X451 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, exchange the entire LOADING COMPLETE
ASSY (T).
*************************************************************
STR BOARD
**********
< CAPACITOR >
C2100 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2101 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2102 1-126-791-11 ELECT 10uF 20% 35V
(SHAKE33)
C2102 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2103 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2104 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2105 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2106 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2107 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2108 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
(SHAKE33)
C2108 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2109 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2110 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
(SHAKE33)
C2110 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE77)
C2111 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2112 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2113 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2114 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2115 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
(SHAKE77)
C2115 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2116 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2117 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2118 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2119 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2120 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2121 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
(SHAKE77)
C2121 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2122 1-126-791-11 ELECT 10uF 20% 35V
(SHAKE77)
C2122 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2123 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
(SHAKE77)
C2123 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
(SHAKE33)
C2125 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE77)
< CONNECTOR >
CN2101 1-784-739-11 CONNECTOR, FFC 17P (SHAKE33)
CN2102 1-784-834-51 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
(SHAKE77)
< DIODE >
D2100 6-503-944-51 DI SMLVN6RGB1U17QYB (SHAKE77)
D2101 6-503-224-02 DI 1L0352V22F3MIT02 (SHAKE33)
MS-476
