Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE33/SHAKE77
118
TUNER BOARD
************
< CAPACITOR >
C3000 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C3001 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C3002 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C3003 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C3004 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C3005 1-117-739-81 CERAMIC CHIP 3PF 0.1PF 16V
C3006 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C3007 1-117-739-81 CERAMIC CHIP 3PF 0.1PF 16V
*
C3008 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*
C3011 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
*
C3013 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN3000 1-774-730-21 PIN, CONNECTOR (PC BOARD) 3P
(ANTENNA FM/AM)
CN3001 1-820-112-51 CONNECTOR, FFC/FPC 9P
< DIODE >
D3000 6-500-400-01 DIODE BAV99-215
D3001 6-500-400-01 DIODE BAV99-215
D3002 6-500-400-01 DIODE BAV99-215
< IC >
IC3000 6-720-234-01 IC RN5B801-0002
IC3001 6-715-134-01 IC MM3404A33URE
< COIL >
L3000 1-469-187-21 INDUCTOR 68nH
L3001 1-457-998-11 COIL, AM ANTENNA
L3002 1-469-187-21 INDUCTOR 68nH
L3003 1-414-576-41 INDUCTOR 47nH
L3004 1-414-455-11 INDUCTOR 2.2nH
< RESISTOR >
R3000 1-218-941-81 METAL CHIP 100 5% 1/16W
R3003 1-216-864-11 SHORT CHIP 0
R3004 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3005 1-218-941-81 METAL CHIP 100 5% 1/16W
R3006 1-218-990-81 SHORT CHIP 0
R3007 1-216-864-11 SHORT CHIP 0
R3008 1-218-933-11 METAL CHIP 22 5% 1/16W
R3009 1-218-933-11 METAL CHIP 22 5% 1/16W
R3010 1-216-864-11 SHORT CHIP 0
R3011 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X3000 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
*************************************************************
MISCELLANEOUS
**************
0
51 1-855-006-51 DC FAN
52 1-828-309-21 WIRE (FLAT TYPE) (9 CORE)
103 1-500-082-11 CLAMP, SLEEVE FERRITE
104 1-828-381-21 WIRE (FLAT TYPE) (23 CORE) (SHAKE77)
104 1-828-994-21 WIRE (FLAT TYPE) (17 CORE) (SHAKE33)
TUNER
Note: If wire (fl at type) is replaced, install it after bending it in the
same form as that before replacement.
105 1-828-382-21 WIRE (FLAT TYPE) (23 CORE)
107 1-492-699-11 BLUETOOTH MODULE
108 1-828-701-61 WIRE (FLAT TYPE) (10 CORE)
154 8-989-470-00 RC-S801/A (WW)
156 1-828-692-61 WIRE (FLAT TYPE) (8 CORE)
201 1-828-369-21 WIRE (FLAT TYPE) (21 CORE)
0
203 1-855-006-41 FAN, DC (SHAKE33)
0
203 1-855-340-11 DC FAN (SHAKE77)
252 1-457-369-12 CORE, FERRITE
0
254 1-834-966-41 POWER-SUPPLY CORD (AEP)
0
254 1-835-068-21 CORD, POWER (AUS)
0
254 1-835-706-22 CORD, POWER-SUPPLY (E51)
0
254 1-837-308-11 CORD, POWER-SUPPLY (US)
0
254 1-837-344-11 CORD, POWER-SUPPLY (E2, MX)
0
254 1-839-999-21 POWER-SUPPLY CORD (UK)
*
256 3-703-150-11 CLAMP
0
257 1-474-551-11 REGULATOR, SWITCHING (3H401W) (SHAKE33)
0
257 1-474-555-11 SWITCHING REGULATOR (SSN-GBR) (SHAKE77)
301 A-1896-391-B LOADING COMPLETE ASSY (T)
(including MS-476 board)
0
304 A-1940-584-A SERVICE, OPTICAL DEVICE
305 1-828-293-21 WIRE (FLAT TYPE) (5 CORE)
306 1-846-951-11 WIRE (FLAT TYPE) (24 CORE)
