Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE5/SHAKE6D
74
C1613 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(SHAKE6D)
C1615 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1616 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1617 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1618 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
(SHAKE6D)
C1619 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1620 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1621 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1622 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1623 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1624 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C1625 1-124-779-00 ELECT CHIP 10uF 20% 16V
C1626 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1627 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1628 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1629 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C1630 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C1631 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1636 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C1637 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1638 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1641 1-124-779-00 ELECT CHIP 10uF 20% 16V
C1642 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1643 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1644 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C1645 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1646 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C1649 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1650 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(SHAKE6D)
C1651 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
(SHAKE6D)
C1652 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(SHAKE6D)
C1655 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
(SHAKE6D)
C1657 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C2000 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2001 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2002 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2003 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2004 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2005 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2006 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2008 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C2009 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2010 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2011 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C2012 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2013 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2014 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2015 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2016 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2017 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2018 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2019 1-124-779-00 ELECT CHIP 10uF 20% 16V
C2020 1-124-779-00 ELECT CHIP 10uF 20% 16V
C2021 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2022 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2023 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C2024 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C2025 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C2026 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C2027 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C2028 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C2029 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C2030 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C2031 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C2032 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C2033 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C2034 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C2035 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2036 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN110 1-820-112-51 CONNECTOR, FFC/FPC 9P
CN150 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN180 1-815-762-31 CONNECTOR, FFC/FPC (LIF) 14P
CN200 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN301 1-691-550-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
CN305 1-843-557-11 FFC ST CONNECTOR (NON-ZIF) 24P
CN306 1-794-362-51 CONNECTOR, FFC/FPC 5P
CN307 1-573-806-21 PIN, CONNECTOR (1.5MM) (SMD) 6P
CN308 1-691-550-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
CN460 1-774-730-21 PIN, CONNECTOR (PC BOARD) 3P
(ANTENNA FM/AM)
CN461 1-774-731-21 PIN, CONNECTOR (PC BOARD) 5P
(FOR SERVICE USE - factory internal use only)
CN901 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN1000 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
* CN1001 1-564-905-11 PIN, CONNECTOR (3.96mm PITCH) 9P
CN1002 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
* CN1504 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER L)
* CN1505 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER R)
CN1507 1-820-384-31 CONNECTOR, FFC/FPC (LIF) 8P
CN1508 1-820-117-51 CONNECTOR, FFC/FPC 19P
CN1509 1-770-468-21 PIN, CONNECTOR (PC BOARD) 10P
< DIODE >
D270 6-503-857-01 DI BAW56
D420 6-502-961-01 DI DA2J10100L
D421 6-502-961-01 DI DA2J10100L
D422 8-719-058-24 DIODE RB501V-40TE-17
D460 6-500-400-01 DIODE BAV99-215
D461 6-500-400-01 DIODE BAV99-215
D462 6-500-400-01 DIODE BAV99-215
D901 8-719-069-29 DIODE RB520S-30FJTE61
D902 8-719-069-29 DIODE RB520S-30FJTE61
D1002 6-502-970-01 DI DZ2J068M0L
D1003 6-502-970-01 DI DZ2J068M0L
D1006 6-503-042-01 DI DZ2J330M0L
D1007 6-502-974-01 DI DZ2J140M0L
D1008 6-503-857-01 DI BAW56
D1009 6-503-857-01 DI BAW56
D1010 6-503-987-01 DI RF05VAM2STR
D1011 6-503-987-01 DI RF05VAM2STR
D1012 6-503-987-01 DI RF05VAM2STR
D1013 6-503-987-01 DI RF05VAM2STR
MOTHERBOARD
