Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE5/SHAKE6D
75
D1014 6-503-987-01 DI RF05VAM2STR
D1015 6-503-987-01 DI RF05VAM2STR
D1016 6-503-987-01 DI RF05VAM2STR
D1017 6-503-987-01 DI RF05VAM2STR
D1018 6-500-514-01 DIODE BAV70
D1019 8-719-058-24 DIODE RB501V-40TE-17
D1023 6-500-514-01 DIODE BAV70
D1024 6-503-857-01 DI BAW56
D1025 6-502-968-01 DI DZ2J062M0L
D1026 6-503-026-01 DI DZ2J120M0L
D1027 6-503-026-01 DI DZ2J120M0L
D1028 6-502-968-01 DI DZ2J062M0L
D1041 6-503-032-01 DI DZ2J180M0L
D1042 6-502-976-01 DI DZ2J150M0L
D1043 6-502-973-01 DI DZ2J091M0L
D1044 6-503-042-01 DI DZ2J330M0L
D1045 6-502-974-01 DI DZ2J140M0L
D1046 6-500-514-01 DIODE BAV70
D1047 6-503-857-01 DI BAW56
D1048 6-503-017-01 DI DZ2J075M0L
< TERMINAL, LUG >
* ET200 1-780-408-11 TERMINAL, LUG
* ET201 1-780-408-11 TERMINAL, LUG
* ET202 1-780-408-11 TERMINAL, LUG
* ET1001 1-780-408-11 TERMINAL, LUG
* ET1003 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB201 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB202 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB203 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB204 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB205 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB206 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB207 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB301 1-216-295-91 SHORT CHIP 0
FB302 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB303 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB304 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB305 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB306 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB307 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB308 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB315 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB462 1-216-864-11 SHORT CHIP 0
FB463 1-216-864-11 SHORT CHIP 0
FB464 1-216-864-11 SHORT CHIP 0
FB465 1-216-864-11 SHORT CHIP 0
FB466 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB467 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB468 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB469 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB470 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB471 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB472 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB473 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB474 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB701 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB902 1-216-295-91 SHORT CHIP 0
< IC >
IC100 A-1968-618-A IC R5F3650MCDFB (for SERVICE)
IC210 6-716-554-21 IC BD9329AEFJ-BZSE2
IC230 6-715-078-01 IC KIA7809AF/API
IC240 6-716-554-21 IC BD9329AEFJ-BZSE2
IC260 6-716-554-21 IC BD9329AEFJ-BZSE2
IC261 6-719-567-01 IC MM1839A40NRE
IC270 6-717-138-01 IC KIA7805AF-RTF/PW
IC280 6-718-580-01 IC BA2903FV-E2
* IC300 6-720-237-01 IC USX2064-AEZG-TR
IC301 6-714-351-01 IC R1EX24016ASAS0A (SHAKE6D)
IC302 6-712-033-01 IC MM1701CHBE
IC303 6-717-694-01 IC BU33TD3WG-TR (SHAKE6D)
IC304 6-718-430-01 IC EM638165 TSB-6G
IC305 6-716-214-01 IC W25Q32BVSSIG-R (SHAKE6D)
IC305 (Not supplied) IC W25Q16CVSSIG-R (SHAKE5)
IC306 (Not supplied) IC CXD9990R (SHAKE6D)
IC306 6-718-440-01 IC CXD90013R (SHAKE5)
IC420 6-718-378-01 IC BU4829F-TR
IC460 6-720-234-01 IC RN5B801-0002
IC461 6-715-134-01 IC MM3404A33URE
IC701 6-716-697-01 IC TAS3108DCPR
IC740 6-707-800-01 IC SRC4182
IC750 6-705-973-01 IC PCM1754DBQR
IC765 6-705-973-01 IC PCM1754DBQR
IC780 8-759-680-48 IC TC7WH157FK
IC902 (Not supplied) IC AM5890S
IC950 8-759-909-71 IC BA4558F
IC951 8-759-909-71 IC BA4558F
IC1000 6-717-191-01 IC KIA7812AF-RTF/PW
IC1001 8-759-394-76 IC NJM2068M-D-TE2
IC1002 8-759-394-76 IC NJM2068M-D-TE2
IC1003 6-720-389-01 IC IRS2092STRPBF-CU
IC1004 6-720-389-01 IC IRS2092STRPBF-CU
IC1005 6-720-389-01 IC IRS2092STRPBF-CU
IC1006 6-720-389-01 IC IRS2092STRPBF-CU
IC1008 6-717-488-01 IC BA4580RF-E2
IC1009 6-717-138-01 IC KIA7805AF-RTF/PW
IC1010 6-717-136-01 IC KIA7905F-RTF/PW
IC1011 6-717-191-01 IC KIA7812AF-RTF/PW
IC1012 6-717-191-01 IC KIA7812AF-RTF/PW
IC1501 6-719-142-01 IC TC62D723FNG
IC1600 8-759-596-39 IC SN74LV4052APWR
IC1601 8-759-596-39 IC SN74LV4052APWR (SHAKE6D)
IC1602 6-710-554-01 IC PCM1808PWR
IC1603 6-710-554-01 IC PCM1808PWR
IC1650 6-720-187-01 IC NJM41031F1 (TE2) (SHAKE6D)
IC2000 8-759-909-71 IC BA4558F
< JACK >
J1600 1-794-981-11 JACK, PIN 4P (AUDIO IN TV/DVD/SAT L/R,
AUDIO IN PC/GAME L/R) (SHAKE5) /
(AUDIO IN TV/SAT L/R, AUDIO IN PC/GAME L/R)
(SHAKE6D)
J1650 1-794-970-11 JACK, PIN 1P (VIDEO OUT) (SHAKE6D)
< COIL >
L211 1-481-903-11 INDUCTOR 33uH
L241 1-481-903-11 INDUCTOR 33uH
MOTHERBOARD
Note 2:
IC305 (SHAKE5), IC306 (SHAKE6D) and IC902 on the
MOTHERBOARD
board cannot exchange with single.
When these parts on the MOTHERBOARD board are
damaged, exchange the entire mounted board.
Note 1: Once IC100 on the MOTHERBOARD board is exchanged,
perform “MODEL & DEST WRITE MODE” (refer page 14)
before operating the set.
To Next Page
