Sony HCD-SHAKEX3 - Panel, Side (L), Panel, Side (R), Panel, Top Assy

HCD-SHAKEX1/SHAKEX3/SHAKEX7
10
5 two tapping screws
qs two tapping
screws
wg top panel section
qg four tapping screws
ql wire (flat type)
(11 core) (CN1004)
qk one screw
(+BVTP 3 u 8)
w; wire (flat type)
(21 core) (CN109)
qh one screw
(+BVTP 3 u 8)
qj one screw
(+BVTP 3 u 8)
qd
6
ws CN451 (8P)
wd CN601 (4P)
wa wire (flat type)
(6 core) (CN105)
1 Insert the
clip etc.
8 Insert the clip etc.
8 Insert the
clip etc.
2 cover screw A
9 cover screw A
0 cover screw B
7 panel, side (L)
qf panel, side (R)
4 one tapping
screw
4 one tapping
screw
4 one tapping
screw
4 one tapping screw
qa one tapping screw
qa one tapping screw
qa one tapping screw
qa one tapping
screw
3 cover screw B
1 Insert the
clip etc.
qh one screw
(+BVTP 3 u 8)
wf
A
B
B
A
STR board
MIC board
DISPLAY board
filament tape
filament tape
filament tape
RC-S730 (WW)
STR board
pin, lead
pin, lead
:LUHVHWWLQJ
:LUHVHWWLQJ
–7RSSDQHOERWWRPYLHZ–
:LUHVHWWLQJ
–7RSSDQHOERWWRPYLHZ–
–7RSSDQHOERWWRPYLHZ–
Note: Follow the disassembly procedure in the numerical order given.
2-1. PANEL, SIDE (L), PANEL, SIDE (R), PANEL, TOP ASSY
Ver. 1.1
