HCD-SHAKEX1/SHAKEX3/SHAKEX7
SECTION 8
ELECTRICAL PARTS LIST
A-2061-403-A 4CH DAMP BOARD, COMPLETE (SHAKEX7)
A-2061-407-A 4CH DAMP BOARD, COMPLETE
(SHAKEX1/SHAKEX3)
*********************
< CAPACITOR >
C1001 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1002 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1005 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
* C1006 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1007 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1009 1-118-978-11 CERAMIC CHIP 0.47uF 10% 250V
* C1012 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1013 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C1014 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
C1015 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
C1016 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1017 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1018 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1019 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1020 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1021 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
C1022 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
C1027 1-124-779-00 ELECT CHIP 10uF 20% 16V
C1028 1-124-779-00 ELECT CHIP 10uF 20% 16V
C1030 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1031 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
C1032 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
C1033 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1034 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1035 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1036 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1039 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
* C1040 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1041 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1043 1-118-978-11 CERAMIC CHIP 0.47uF 10% 250V
* C1046 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1047 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
C1048 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
C1049 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1050 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1060 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
(SHAKEX7)
C1061 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
(SHAKEX7)
C1064 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
(SHAKEX7)
* C1065 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
(SHAKEX7)
C1066 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
(SHAKEX7)
C1068 1-118-978-11 CERAMIC CHIP 0.47uF 10% 250V
(SHAKEX7)
* C1071 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
(SHAKEX7)
C1072 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
(SHAKEX7)
C1073 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
(SHAKEX7)
C1074 1-118-977-11 CERAMIC CHIP 0.22uF 10% 100V
(SHAKEX7)
C1075 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
(SHAKEX7)
C1076 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
(SHAKEX7)
C1077 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
(SHAKEX7)
C1078 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
(SHAKEX7)
C1079 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
(SHAKEX7)
C1080 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
(SHAKEX7)
C1081 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
(SHAKEX7)
C1086 1-124-779-00 ELECT CHIP 10uF 20% 16V
(SHAKEX7)
C1087 1-124-779-00 ELECT CHIP 10uF 20% 16V
(SHAKEX7)
C1089 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
(SHAKEX7)
C1090 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
(SHAKEX7)
C1091 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
(SHAKEX7)
C1092 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
(SHAKEX7)
C1093 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
(SHAKEX7)
C1094 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
(SHAKEX7)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
4CH DAMP
• Abbreviation
AR : Argentina model
AUS : Australian model
E4 : African model
E12 : 220 – 240 V AC area in E models
EA : Saudi Arabia model
LA9 : Latin-American model
MY : Malaysia model
RU : Russian model
TH : Thai model
When indicating parts by reference num-
ber, please include the board name.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Ver. 1.1
