2-8. REGULATOR, SWITCHING (SSN-152AD) (SHAKEX1/SHAKEX3),
SWITCHING REGULATOR (SHAKEX7)
G
G
qa six screws
(+PWH 3 u 8
(SUMITITE))
qf REGULATOR,
SWITCHING
(SSN-152AD)
qg chassis assy (RAI)
(SHAKEX1/SHAKEX3) (SHAKEX7)
(SHAKEX7)
F
G
G
F
F
D
DD
E
EE
7 one screw
(+BVTP 3 u 8)
3 one screw
(+BVTP 3 u 8)
5 stopper, wiring
6 bracket (SQ)
7 two screws
(+BVTP 3 u 8)
0 chassis, sub assy
qd CN1 (2P)
4 one screw
(+BV3 (3-CR))
8 two screws
(+BV3 (3-CR))
9 bracket, L
1 one screw
(+BV3 (3-CR))
2 stopper,
wiring
qa six screws
(+PWH 3 u 8
(SUMITITE))
qa one screw
(+PWH 3 u 8
(SUMITITE))
qa two screws
(+PWH 3 u 8
(SUMITITE))
qf SWITCHING
REGULATOR
qg chassis assy (RYU)
qs stopper,
wiring
qd CN1 (2P)
qa one screw
(+PWH 3 u 8
(SUMITITE))
qa two screws
(+PWH 3 u 8
(SUMITITE))
qs stopper,
wiring
1 one screw
(+BV3 (3-CR))
2 stopper,
wiring
