Sony HCD-SHAKEX3 - 4 CH DAMP Board

HCD-SHAKEX1/SHAKEX3/SHAKEX7
11
2-2. 4CH DAMP BOARD
Ver. 1.3
1 three screws
(+BVTP 3 u 8)
ql five screws
(+BVTP 3 u 8)
8 one screw
(+BVTP 3 u 8)
9 one screw
(+BVTP 3 u 8)
9 one screw
(+BVTP 3 u 8)
0 bracket, fan
(white: SHAKEX1/
SHAKEX3)
(black: SHAKEX7)
qa DC fan
ws 4CH DAMP
board
wa bracket,
heat sink
w;
2 two screws
(+BVTP 3 u 8)
3 two screws
(+BVTP 3 u 8)
qf one screw
(+BVTP 3 u 8)
qf one screw
(+BVTP 3 u 8)
5 bracket, tunnel
(SHAKEX7)
(SHAKEX7)
4 Remove the wire
from the hook.
qs wire (flat type)
(21 core) (CN1009)
qd CN1001 (10P)
6 CN1011 (2P)
7 CN1003
(2P)
(SHAKEX7)
rear side
bracket, tunnel
hook
:LUHVHWWLQJ
C
C
qg three screws
(+PTPWH 2.6 u L
(DIA8.0))
qk heat sink (M3)
qh sheet, thermal
qj cushion, seal
qh sheet,
thermal
(SHAKEX7)
(SHAKEX7)
(SHAKEX1/SHAKEX3)
(SHAKEX1/
SHAKEX3)
