Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKEX1/SHAKEX3/SHAKEX7
79
CN1003 1-843-885-11 PIN, CONNECTOR (PC BOARD) 2P
CN1009 1-820-119-51 CONNECTOR, FFC/FPC 21P
CN1011 1-843-885-11 PIN, CONNECTOR (PC BOARD) 2P (SHAKEX7)
< DIODE >
D1000 6-503-987-01 DI RF05VAM2STR
D1001 6-503-987-01 DI RF05VAM2STR
D1002 6-503-999-01 DI RF201L2SFJTE25
D1003 6-503-999-01 DI RF201L2SFJTE25
D1004 6-503-987-01 DI RF05VAM2STR
D1005 6-503-999-01 DI RF201L2SFJTE25
D1006 6-503-999-01 DI RF201L2SFJTE25
D1007 6-503-987-01 DI RF05VAM2STR
D1008 6-503-987-01 DI RF05VAM2STR
D1009 6-503-987-01 DI RF05VAM2STR
D1010 6-503-987-01 DI RF05VAM2STR (SHAKEX7)
D1011 6-503-987-01 DI RF05VAM2STR (SHAKEX7)
D1012 6-503-999-01 DI RF201L2SFJTE25 (SHAKEX7)
D1013 6-503-999-01 DI RF201L2SFJTE25 (SHAKEX7)
D1014 6-503-987-01 DI RF05VAM2STR (SHAKEX7)
D1015 6-503-999-01 DI RF201L2SFJTE25 (SHAKEX7)
D1016 6-503-999-01 DI RF201L2SFJTE25 (SHAKEX7)
D1017 6-503-987-01 DI RF05VAM2STR (SHAKEX7)
D1018 6-503-987-01 DI RF05VAM2STR (SHAKEX7)
D1019 6-503-987-01 DI RF05VAM2STR (SHAKEX7)
D1020 6-502-970-01 DI DZ2J068M0L
D1021 6-503-026-01 DI DZ2J120M0L
D1022 6-502-970-01 DI DZ2J068M0L
D1023 6-503-857-01 DI BAW56
D1024 6-500-514-01 DIODE BAV70
* D1025 6-503-578-01 DI RB520SM-30T2R
* D1027 6-503-578-01 DI RB520SM-30T2R (SHAKEX7)
D1030 6-500-514-01 DIODE BAV70
D1032 6-504-003-01 DI RB578VAM100TR
D1033 6-504-003-01 DI RB578VAM100TR (SHAKEX7)
< IC >
IC1005 6-722-001-01 IC 78D12AG-TN3-R
IC1006 6-722-002-01 IC 78D07AG-TN3-R
IC1007 6-722-003-01 IC 79D07AG-TN3-R
IC1008 (Not supplied) IC CXD90038ER
IC1009 6-721-937-01 IC BD34700FV-E2
IC1010 (Not supplied) IC CXD90038ER (SHAKEX7)
< COIL >
L1001
1-482-160-21 INDUCTOR 20uH
L1003 1-482-160-21 INDUCTOR 20uH
L1006 1-482-160-21 INDUCTOR 20uH (SHAKEX7)
L1008 1-482-160-21 INDUCTOR 20uH (SHAKEX7)
< TRANSISTOR >
Q1000 6-552-698-01 TR IRF6775MTR1PBF
Q1001 6-552-698-01 TR IRF6775MTR1PBF
Q1002 8-729-013-28 TR HN1B01FU
Q1003 8-729-427-72 TRANSISTOR XP4501
Q1004 6-552-698-01 TR IRF6775MTR1PBF
Q1005 6-552-698-01 TR IRF6775MTR1PBF
Q1006 6-552-698-01 TR IRF6775MTR1PBF (SHAKEX7)
Q1007 6-552-698-01 TR IRF6775MTR1PBF (SHAKEX7)
Q1008 8-729-013-28 TR HN1B01FU (SHAKEX7)
Q1009 8-729-427-72 TRANSISTOR XP4501 (SHAKEX7)
Q1010 6-552-698-01 TR IRF6775MTR1PBF (SHAKEX7)
Q1011 6-552-698-01 TR IRF6775MTR1PBF (SHAKEX7)
Q1012 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q1013 8-729-905-35 TRANSISTOR 2SC4081-R
Q1014 6-552-922-01 TR LTA014EUBFS8TL
Q1015 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1016 6-550-978-01 TR RN1902
Q1018 6-550-978-01 TR RN1902
Q1019 8-729-013-28 TR HN1B01FU
Q1020 6-552-746-01 TR DSA700300L
Q1021 8-729-427-72 TRANSISTOR XP4501
Q1022 6-552-746-01 TR DSA700300L (SHAKEX7)
Q1023 6-552-892-01 TR LSCR523UBFS8TL
Q1024 6-552-892-01 TR LSCR523UBFS8TL (SHAKEX7)
Q1025 8-729-905-35 TRANSISTOR 2SC4081-R
< RESISTOR >
R1000 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1001 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1003 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1004 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1005 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R1006 1-216-797-11 METAL CHIP 10 5% 1/10W
R1007 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1008 1-216-797-11 METAL CHIP 10 5% 1/10W
R1009 1-216-797-11 METAL CHIP 10 5% 1/10W
R1010 1-216-797-11 METAL CHIP 10 5% 1/10W
R1011 1-218-869-11 METAL CHIP 8.2K 0.5% 1/10W
R1013 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1014 1-257-604-11 RES-CHIP 47 5% 2W
R1017 1-257-604-11 RES-CHIP 47 5% 2W
R1020 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R1021 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1022 1-216-846-11 METAL CHIP 120K 5% 1/10W
R1023 1-216-246-00 METAL CHIP 100K 5% 1/8W
R1024 1-216-840-11 METAL CHIP 39K 5% 1/10W
R1025 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R1026 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R1027 1-216-847-11 METAL CHIP 150K 5% 1/10W
R1028 1-216-864-11 SHORT CHIP 0
R1029 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1030 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1031 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1033 1-216-246-00 METAL CHIP 100K 5% 1/8W
R1036 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1037 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1038 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1039 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1040 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R1041 1-216-864-11 SHORT CHIP 0
R1042 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1043 1-216-797-11 METAL CHIP 10 5% 1/10W
R1044 1-216-797-11 METAL CHIP 10 5% 1/10W
R1045 1-216-797-11 METAL CHIP 10 5% 1/10W
R1047 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1048 1-257-604-11 RES-CHIP 47 5% 2W
R1051 1-257-604-11 RES-CHIP 47 5% 2W
R1054 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R1055 1-216-864-11 SHORT CHIP 0
R1056 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1057 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
4CH DAMP
Note: IC1008 and IC1010 on the 4CH DAMP board cannot
exchange with single. When these parts on the 4CH DAMP
board are damaged, exchange the entire mounted board.
Ver. 1.3
