Sony HCD-SR1 - Printed Wiring Board - DMB08 Board (Side A)

1313
HCD-SR1/SR2/SR3
HCD-SR1/SR2/SR3
3-5. PRINTED WIRING BOARD — DMB08 BOARD (SIDE A) —
• See page 8 for Circuit Boards Location. :Uses unleaded solder.
IC401
IC301
IC901
IC813
IC612
IC605
IC606
IC801
IC607
IC701
IC206
IC402
D
DDCON
BOARD
CN800
(Page 34)
FOR
CHECK
FOR
CHECK
A
RF
BOARD
CN002
(Page 11)
F
IO
BOARD
CN201
(Page 31)
E
IO
BOARD
CN601
(Page 31)
SWITCHING
REGULATOR
CN8
C
AMP
BOARD
CN301
(Page 26)
B
AMP
BOARD
CN302
(Page 26)
G
DRIVER
BOARD
CN701
(Page 12)
12
A
B
C
D
E
F
3456789
• Semiconductor
Location
Ref. No. Location
D900 C-2
D901 C-4
IC206 D-5
IC301 C-2
IC401 D-2
IC402 D-2
IC605 C-8
IC606 C-7
IC607 B-7
IC612 B-6
IC701 D-4
IC801 B-5
IC813 C-4
IC901 B-2
