Sony HCD-SR1 - 3 Diagrams

8
HCD-SR1/SR2/SR3
SECTION 3
DIAGRAMS
• Circuit Boards Location
AMP board
SPK board
IO board
TUNER UNIT
DMB08 board
LF board
HP board
FL board
SONY LAMP board
PW KEY board
CONTROL KEY board
DRIVER board
RF board
DDCON board
SWITCHING REGLATOR
SCART board
(only for AEP, UK and Russian models)
