Sony HCD-SR1 - Printed Wiring Board - DDCON Board

3434
HCD-SR1/SR2/SR3
HCD-SR1/SR2/SR3
3-26. PRINTED WIRING BOARD — DDCON BOARD —
• See page 8 for Circuit Boards Location. :Uses unleaded solder.
O
FL
BOARD
CN803
(Page 36)
14
15
D
DMB08
BOARD
CN005
(Page 13)
12
A
B
C
D
34567
• Semiconductor
Location
Ref. No. Location
D810 C-5
D811 C-5
D813 C-5
D814 C-5
D815 C-3
Q802 C-6
