Sony HCD-SR1 - Printed Wiring Board - RF Board

1010
HCD-SR1/SR2/SR3
HCD-SR1/SR2/SR3
3-1. PRINTED WIRING BOARD — RF BOARD —
• See page 8 for Circuit Boards Location. :Uses unleaded solder.
(SIDE A)
RF BOARD
(SIDE B)
RF BOARD
IC001
DMB08 BOARD
CN401
(Page 13)
A
E
E
OPTICAL PICK-UP
BLOCK
(TDP022W)
FLEXIBLE BOARD
1-684-822-
11
(11)
1-684-822-
11
(11)
1
16
17 32
48
33
64 49
1 2 3 4 5 6 7 8 9 10 11 12 13
A
B
C
D
E
F
• Semiconductor
Location
Ref. No. Location
D001 B-3
D002 B-3
IC001 D-11
Q001 C-11
Q002 B-11
