66
HCD-SR1/SR2/SR3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< IC >
IC001 8-752-417-53 IC CXD1881AR
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R001 1-218-668-11 METAL CHIP 100 0.5% 1/16W
R003 1-216-803-11 METAL CHIP 33 5% 1/10W
R004 1-216-803-11 METAL CHIP 33 5% 1/10W
R005 1-216-841-11 METAL CHIP 47K 5% 1/10W
R006 1-216-817-11 METAL CHIP 470 5% 1/10W
R007 1-216-803-11 METAL CHIP 33 5% 1/10W
R008 1-216-803-11 METAL CHIP 33 5% 1/10W
R009 1-216-841-11 METAL CHIP 47K 5% 1/10W
R010 1-216-817-11 METAL CHIP 470 5% 1/10W
R011 1-216-864-11 METAL CHIP 0 5% 1/10W
R012 1-216-864-11 METAL CHIP 0 5% 1/10W
R013 1-216-864-11 METAL CHIP 0 5% 1/10W
R014 1-216-864-11 METAL CHIP 0 5% 1/10W
R015 1-216-864-11 METAL CHIP 0 5% 1/10W
R016 1-216-864-11 METAL CHIP 0 5% 1/10W
R017 1-216-864-11 METAL CHIP 0 5% 1/10W
R018 1-216-864-11 METAL CHIP 0 5% 1/10W
R019 1-216-864-11 METAL CHIP 0 5% 1/10W
R020 1-216-864-11 METAL CHIP 0 5% 1/10W
R021 1-216-864-11 METAL CHIP 0 5% 1/10W
R022 1-216-813-11 METAL CHIP 220 5% 1/10W
R023 1-216-820-11 METAL CHIP 820 5% 1/10W
R024 1-216-864-11 METAL CHIP 0 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/16W
R027 1-216-864-11 METAL CHIP 0 5% 1/10W
R028 1-216-864-11 METAL CHIP 0 5% 1/10W
R029 1-216-864-11 METAL CHIP 0 5% 1/10W
R032 1-216-809-11 METAL CHIP 100 5% 1/10W
R033 1-216-864-11 METAL CHIP 0 5% 1/10W
R034 1-219-570-11 RES-CHIP 10M 5% 1/10W
R035 1-216-864-11 METAL CHIP 0 5% 1/10W
R041 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
SCART BOARD (AEP, UK, RU)
************************
< CAPACITOR >
C230 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU)
C231 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU)
< JACK >
J203 1-815-911-11 CONNECTOR, SQUARE TYPE 21P
(EURO AV T OUTPUT (TO TV))
(AEP, UK, RU)
************************************************************
1-861-987-12 SONY LAMP BOARD
****************
< CAPACITOR >
C862 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C863 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN806 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D819 6-500-929-01 DIODE SML-512WBCW1AR (SONY)
D821 6-500-929-01 DIODE SML-512WBCW1AR (SONY)
< RESISTOR >
R846 1-216-809-11 METAL CHIP 100 5% 1/10W
R847 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
SPK BOARD
**********
< CAPACITOR >
C340 1-162-294-31 CERAMIC 0.001uF 10% 50V
C341 1-162-294-31 CERAMIC 0.001uF 10% 50V
C342 1-162-294-31 CERAMIC 0.001uF 10% 50V
C343 1-162-294-31 CERAMIC 0.001uF 10% 50V
C483 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C484 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C487 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C488 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C491 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C492 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C493 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C494 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C495 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C496 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN309 1-564-243-11 PIN, CONNECTOR (3.96mm PITCH) 6P
CN311 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN312 1-691-766-21 PLUG (MICRO CONNECTOR) 4P
< GROUND TERMINAL >
GP307 1-537-770-21 TERMINAL BOARD, GROUND
< TERMINAL >
TB301 1-780-122-11 TERMINAL BOARD (SPEAKER)
TB302 1-780-121-11 TERMINAL BOARD (SPEAKER)
************************************************************
RF SCART SONY LAMP SPK
