65
HCD-SR1/SR2/SR3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R643 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP, UK, RU)
R644 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP, UK, RU)
R645 1-216-809-11 METAL CHIP 100 5% 1/10W
R647 1-216-833-11 METAL CHIP 10K 5% 1/10W
R648 1-216-833-11 METAL CHIP 10K 5% 1/10W
R649 1-216-839-11 METAL CHIP 33K 5% 1/10W
R650 1-216-821-11 METAL CHIP 1K 5% 1/10W
R651 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R652 1-216-833-11 METAL CHIP 10K 5% 1/10W
R653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R654 1-216-813-11 METAL CHIP 220 5% 1/10W
R655 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R656 1-216-841-11 METAL CHIP 47K 5% 1/10W
R657 1-216-833-11 METAL CHIP 10K 5% 1/10W
R659 1-216-821-11 METAL CHIP 1K 5% 1/10W
R661 1-216-813-11 METAL CHIP 220 5% 1/10W
R664 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< VIBRATOR >
X101 1-579-900-21 VIBRATOR, CRYSTAL 4.332MHz (AEP, UK, RU)
************************************************************
LF BOARD
********
< CAPACITOR >
0 C903 1-117-916-51 FILM 0.22uF 10% 275V
< CONNECTOR >
CN900 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN901 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
< LINE FILTER >
0 LF901 1-456-081-21 COIL, LINE FILTER
************************************************************
PW KEY BOARD
*************
< CAPACITOR >
C811 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
* CN805 1-568-941-11 PIN, CONNECTOR 3P
< DIODE >
D802 6-500-817-01 DIODE (LED) SML-512UWT86 (?/1)
< RESISTOR >
R809 1-216-864-11 SHORT CHIP 0
< SWITCH >
S800 1-771-884-31 SWITCH, TACTILE (?/1)
************************************************************
A-4728-690-A RF BOARD, COMPLETE
******************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
C006 1-128-993-21 ELECT CHIP 22uF 20% 10V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C010 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C011 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C016 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C017 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C018 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C023 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C037 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C038 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C039 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C042 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN003 1-784-861-21 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
IO LF
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
