HCD-SR1/SR2/SR3
Ref. No. Part No. Description Remark
MISCELLANEOUS
**************
5 1-828-962-11 WIRE (FLAT TYPE) (11 CORE)
0 8 1-696-169-51 CORD, POWER (AEP, UK, RU, HK, SP)
0 8 1-696-847-22 CORD, POWER (AUS)
0 8 1-751-520-21 CORD, POWER (EA)
0 8 1-769-079-32 CORD, POWER (KR)
9 1-763-861-12 FAN, DC
54 1-829-279-11 FLEXIBLE FLAT CABLE (7 CORE)
63 1-828-350-11 WIRE (FLAT TYPE) (17 CORE)
0 105 1-468-839-12 REGULATOR, SWITCHING
108 1-828-339-11 WIRE (FLAT TYPE) (15 CORE)
109 1-828-409-11 WIRE (FLAT TYPE) (29 CORE)
110 1-829-280-11 FLEXIBLE FLAT CABLE (15 CORE)
111 1-828-411-11 WIRE (FLAT TYPE) (29 CORE)
112 1-828-310-11 WIRE (FLAT TYPE) (9 CORE)
113 1-829-281-11 FLEXIBLE FLAT CABLE (17 CORE)
602 1-685-250-11 PWB, FLEXIBLE
0 605 1-477-263-11 OPTICAL PICK-UP (TDP022W)
M701 X-4955-496-1 MOTOR (PULLEY) ASSY (LOADING)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
