Sony HCD-SR1 - Page 87

9
HCD-SR1/SR2/SR3
1-13. RF BOARD
5 RF board
3 wire (flat type)
(CN003)
4 wire (flat type)
(CN001)
1 claw
2 claw
1-14. OPTICAL PICK-UP (DBU-1)
1 two step screws (M
)
2 step screw (M)
3 two insulators
4 insulator
5 optical pick-up
(DBU-1)
