12
HCD-U1BT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C206 1-126-960-11 ELECT 1uF 20% 50V
C212 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C213 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C214 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C215 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C216 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C217 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C220 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C221 1-126-923-91 ELECT 220uF 20% 10V
C222 1-126-923-91 ELECT 220uF 20% 10V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C224 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C227 1-126-960-11 ELECT 1uF 20% 50V
C228 1-126-960-11 ELECT 1uF 20% 50V
C229 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C230 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C231 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C232 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C250 1-126-960-11 ELECT 1uF 20% 50V
C251 1-126-960-11 ELECT 1uF 20% 50V
C252 1-126-960-11 ELECT 1uF 20% 50V
C254 1-126-960-11 ELECT 1uF 20% 50V
C255 1-126-960-11 ELECT 1uF 20% 50V
C256 1-126-960-11 ELECT 1uF 20% 50V
C260 1-126-960-11 ELECT 1uF 20% 50V
C261 1-126-960-11 ELECT 1uF 20% 50V
C262 1-126-960-11 ELECT 1uF 20% 50V
C264 1-126-960-11 ELECT 1uF 20% 50V
C265 1-126-960-11 ELECT 1uF 20% 50V
C266 1-126-960-11 ELECT 1uF 20% 50V
C267 1-126-960-11 ELECT 1uF 20% 50V
C268 1-126-960-11 ELECT 1uF 20% 50V
< CONNECTOR >
CN102 1-815-444-11 PIN, CONNECTOR (PWB) 3P
CN103 1-784-737-11 CONNECTOR, FFC 15P
CN104 1-819-130-11 PIN, CONNECTOR 2P
CN105 1-819-131-11 PIN, CONNECTOR 3P
CN107 1-784-726-11 CONNECTOR, FFC 4P
CN108 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CN109 1-784-780-11 CONNECTOR, FFC 19P
CN110 1-568-828-11 CONNECTOR, FFC 9P (US, CND, KR)
CN110 1-568-830-11 CONNECTOR, FFC 11P (AEP, UK)
CN113 1-784-776-11 CONNECTOR, FFC 15P
CN114 1-568-828-11 CONNECTOR, FFC 9P
CN115 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN116 1-815-449-11 PIN, CONNECTOR (PWB) 8P
< DIODE >
D102 6-500-080-11 DIODE 21DQ04N-TA2B1
D103 8-719-000-07 DIODE MC2836
D104 8-719-000-07 DIODE MC2836
D105 8-719-000-07 DIODE MC2836
D106 6-501-172-01 DIODE UDZW-TE17-8.2B
D107 6-501-193-01 DIODE 1SS355WTE-17
D108 8-719-063-79 DIODE 1N4002B
D109 8-719-063-79 DIODE 1N4002B
D111 8-719-000-07 DIODE MC2836
D201 6-501-193-01 DIODE 1SS355WTE-17
D251 6-501-193-01 DIODE 1SS355WTE-17
D252 6-501-172-01 DIODE UDZW-TE17-8.2B
D253 6-501-193-01 DIODE 1SS355WTE-17
< EARTH TERMINAL >
EP201 1-537-771-21 TERMINAL BOARD, GROUND
< FUSE >
0 F101 1-532-464-33 FUSE (T2.5AL/250V)
< COIL >
FB201 1-412-473-21 INDUCTOR (SMALL TYPE)
< IC >
IC103 8-759-640-19 IC PQ1CG2032FZ
IC106 8-759-646-53 IC KIA7812API
IC107 6-806-658-01 IC M30624MGP-A57FPU0
IC108 6-701-680-01 IC PST3629NR
IC109 8-759-656-83 IC NJM4580MD-(TE2)
IC110 6-701-824-11 IC BD3870FS-E2
IC112 8-759-430-37 IC MC14052BDTR2
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR105 1-216-864-11 SHORT CHIP 0
JR107 1-216-864-11 SHORT CHIP 0
JR108 1-216-864-11 SHORT CHIP 0
JR109 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-400-424-11 INDUCTOR 47uH
L102 1-400-424-11 INDUCTOR 47uH
L103 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q104 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q105 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q107 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q108 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q109 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q110 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q111 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q112 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q113 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q114 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q115 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q116 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q117 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q119 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q121 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q122 8-729-027-43 TRANSISTOR DTC114EKA-T146
MAIN
Ver. 1.3
