11
HCD-U1BT
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
CND : Canadian model
KR : Korean model
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1178-318-A HP BOARD, COMPLETE
*******************
1-833-049-21 CABLE, FLEXIBLE FLAT (9 CORE)
< CAPACITOR >
C621 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C622 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C623 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C624 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C625 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C626 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C627 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C629 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< DIODE >
D601 6-500-848-01 DIODE MC2840-T112-1
D602 6-500-848-01 DIODE MC2840-T112-1
< EARTH TERMINAL >
* EP601 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB619 1-500-329-21 INDUCTOR, FERRITE BEAD
FB620 1-216-821-11 METAL CHIP 1K 5% 1/10W
FB621 1-500-329-21 INDUCTOR, FERRITE BEAD
FB622 1-500-329-21 INDUCTOR, FERRITE BEAD
FB623 1-500-329-21 INDUCTOR, FERRITE BEAD
< JACK >
J620 1-815-629-11 JACK (AUDIO IN)
J621 1-815-629-11 JACK (i)
< RESISTOR >
R620 1-216-821-11 METAL CHIP 1K 5% 1/10W
R621 1-216-845-11 METAL CHIP 100K 5% 1/10W
R622 1-216-845-11 METAL CHIP 100K 5% 1/10W
R623 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R624 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
*************************************************************
A-1188-677-A MAIN BOARD, COMPLETE (AEP, UK)
A-1188-694-A MAIN BOARD, COMPLETE (US, CND)
A-1216-974-A MAIN BOARD, COMPLETE (KR)
*********************
1-533-233-31 FUSE HOLDER
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C103 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C104 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C106 1-128-952-31 ELECT 220uF 20% 25V
C109 1-126-937-11 ELECT 4700uF 20% 16V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-126-935-11 ELECT 470uF 20% 16V
C115 1-128-951-21 ELECT 2200uF 20% 16V
C117 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C118 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C119 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C120 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C121 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C124 1-126-916-11 ELECT 1000uF 20% 6.3V
C125 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C128 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C129 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C134 1-126-923-91 ELECT 220uF 20% 10V
C135 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C136 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C137 1-126-923-91 ELECT 220uF 20% 10V
C149 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C150 1-126-923-91 ELECT 220uF 20% 10V
C151 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C152 1-126-923-91 ELECT 220uF 20% 10V
C153 1-126-923-91 ELECT 220uF 20% 10V
C154 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C155 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C156 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C157 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C162 1-126-964-11 ELECT 10uF 20% 50V
C165 1-126-960-11 ELECT 1uF 20% 50V
C166 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C169 1-126-933-11 ELECT 100uF 20% 16V
C170 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C171 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C172 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C175 1-126-960-11 ELECT 1uF 20% 50V
C182 1-126-933-11 ELECT 100uF 20% 16V
C183 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C184 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C188 1-126-923-91 ELECT 220uF 20% 10V
C205 1-126-960-11 ELECT 1uF 20% 50V
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
MAINHP
Ver. 1.3
