Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CD SW
CONNECTOR
A-4417-826-A CD-SW BOARD, COMPLETE
*********************
< DIODE >
D751 8-719-056-13 DIODE SML79423C-TP15 (DISC 1)
D752 8-719-056-13 DIODE SML79423C-TP15 (DISC 2)
D753 8-719-056-13 DIODE SML79423C-TP15 (DISC 3)
D754 8-719-063-93 DIODE SLR325VC-N-T32 (1/u)
< RESISTOR >
R751 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-249-418-11 CARBON 1.2K 5% 1/4W F
R753 1-249-420-11 CARBON 1.8K 5% 1/4W F
R754 1-249-422-11 CARBON 2.7K 5% 1/4W F
R755 1-247-843-11 CARBON 3.3K 5% 1/4W
R756 1-249-425-11 CARBON 4.7K 5% 1/4W F
R757 1-249-427-11 CARBON 6.8K 5% 1/4W F
R758 1-247-804-11 CARBON 75 5% 1/4W
R759 1-249-407-11 CARBON 150 5% 1/4W F
R760 1-247-804-11 CARBON 75 5% 1/4W
R761 1-249-407-11 CARBON 150 5% 1/4W F
R762 1-247-804-11 CARBON 75 5% 1/4W
R763 1-249-407-11 CARBON 150 5% 1/4W F
R764 1-249-414-11 CARBON 560 5% 1/4W F
< SWITCH >
S751 1-762-875-21 SWITCH, KEYBOARD (1/u)
S752 1-762-875-21 SWITCH, KEYBOARD (DEMO (STANDBY))
S753 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S754 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S755 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S756 1-762-875-21 SWITCH, KEYBOARD (EXCHANGE DISC SKIP)
S757 1-762-875-21 SWITCH, KEYBOARD (§)
**************************************************************
* 1-658-575-11 CONNECTOR BOARD
***************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
A-4426-201-A FRONT AMP BOARD, COMPLETE
*************************
< CAPACITOR >
C801 1-126-963-11 ELECT 4.7uF 20% 50V
C802 1-162-286-21 CERAMIC 220PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-104-664-11 ELECT 47uF 20% 10V
C806 1-128-560-11 ELECT 22uF 20% 100V
C807 1-130-777-00 FILM 0.1uF 10% 100V
C808 1-136-495-11 FILM 0.068uF 5% 50V
C809 1-136-495-11 FILM 0.068uF 5% 50V
C821 1-126-960-11 ELECT 1uF 20% 50V
C822 1-162-306-11 CERAMIC 0.01uF 20% 16V
C825 1-104-665-11 ELECT 100uF 20% 10V
C826 1-126-961-11 ELECT 2.2uF 20% 50V
C827 1-104-665-11 ELECT 100uF 20% 10V
C831 1-126-563-11 ELECT 100uF 20% 100V
C851 1-126-963-11 ELECT 4.7uF 20% 50V
C852 1-162-286-21 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-104-664-11 ELECT 47uF 20% 10V
C856 1-128-560-11 ELECT 22uF 20% 100V
C857 1-130-777-00 FILM 0.1uF 10% 100V
C858 1-136-495-11 FILM 0.068uF 5% 50V
C859 1-136-495-11 FILM 0.068uF 5% 50V
C880 1-126-963-11 ELECT 4.7uF 20% 50V
C881 1-127-751-11 ELECT 3300uF 20% 50V
C882 1-127-751-11 ELECT 3300uF 20% 50V
C883 1-127-753-11 ELECT 3300uF 20% 71V
C884 1-127-753-11 ELECT 3300uF 20% 71V
C885 1-136-165-00 FILM 0.1uF 5% 50V
C886 1-136-165-00 FILM 0.1uF 5% 50V
C887 1-130-777-00 FILM 0.1uF 10% 100V
C888 1-130-777-00 FILM 0.1uF 10% 100V
C889 1-164-159-21 CERAMIC 0.1uF 50V
C890 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN801 1-770-722-11 CONNECTOR, BOARD TO BOARD 6P
CN802 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-110-09 DIODE RD8.2ES-B3
D802 8-719-991-33 DIODE 1SS133T-77
D821 8-719-991-33 DIODE 1SS133T-77
D831 8-719-991-33 DIODE 1SS133T-77
D851 8-719-110-09 DIODE RD8.2ES-B3
D852 8-719-991-33 DIODE 1SS133T-77
D871 8-719-991-33 DIODE 1SS133T-77
D881 8-719-510-68 DIODE D5SBA20F01
D882 8-719-510-68 DIODE D5SBA20F01
D883 8-719-991-33 DIODE 1SS133T-77
D884 8-719-991-33 DIODE 1SS133T-77
D885 8-719-991-33 DIODE 1SS133T-77
< GROUND PLATE >
* EP802 1-537-738-21 TERMINAL, EARTH
< IC >
IC801 8-749-016-11 IC STK411-230M
FRONT AMP
