– 104 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q821 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q822 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q825 8-729-119-78 TRANSISTOR 2SC403SP-51
Q826 8-729-119-78 TRANSISTOR 2SC403SP-51
Q827 8-729-119-78 TRANSISTOR 2SC403SP-51
Q828 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q829 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q830 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q832 8-729-119-78 TRANSISTOR 2SC403SP-51
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q881 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q882 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q883 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q884 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q885 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q886 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-249-416-11 CARBON 820 5% 1/4W F
R804 1-249-438-11 CARBON 56K 5% 1/4W
! R805 1-212-881-11 FUSIBLE 100 5% 1/4W F
R806 1-260-335-11 CARBON 3.9K 5% 1/2W
! R807 1-217-156-00 METAL 0.22 10% 5W
R808 1-249-417-11 CARBON 1K 5% 1/4W F
R809 1-249-431-11 CARBON 15K 5% 1/4W
R810 1-249-441-11 CARBON 100K 5% 1/4W
R811 1-260-076-11 CARBON 10 5% 1/2W
R814 1-249-437-11 CARBON 47K 5% 1/4W
R821 1-249-435-11 CARBON 33K 5% 1/4W
R822 1-247-863-91 CARBON 22K 5% 1/4W
R823 1-249-439-11 CARBON 68K 5% 1/4W
R824 1-249-421-11 CARBON 2.2K 5% 1/4W F
R825 1-247-863-91 CARBON 22K 5% 1/4W
R826 1-249-429-11 CARBON 10K 5% 1/4W
R827 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R828 1-202-972-61 FUSIBLE 1 5% 1/4W F
R832 1-249-431-11 CARBON 15K 5% 1/4W
R833 1-249-435-11 CARBON 33K 5% 1/4W
R835 1-249-425-11 CARBON 4.7K 5% 1/4W F
R836 1-249-425-11 CARBON 4.7K 5% 1/4W F
R837 1-247-863-91 CARBON 22K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
R839 1-249-429-11 CARBON 10K 5% 1/4W
R840 1-249-429-11 CARBON 10K 5% 1/4W
R841 1-249-437-11 CARBON 47K 5% 1/4W
R842 1-249-438-11 CARBON 56K 5% 1/4W
R843 1-249-439-11 CARBON 68K 5% 1/4W
R844 1-249-438-11 CARBON 56K 5% 1/4W
R845 1-249-437-11 CARBON 47K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-249-416-11 CARBON 820 5% 1/4W F
R854 1-249-438-11 CARBON 56K 5% 1/4W
! R855 1-212-881-11 FUSIBLE 100 5% 1/4W F
R856 1-260-335-11 CARBON 3.9K 5% 1/2W
! R857 1-217-156-00 METAL 0.22 10% 5W
R858 1-249-417-11 CARBON 1K 5% 1/4W F
R859 1-249-431-11 CARBON 15K 5% 1/4W
R860 1-249-441-11 CARBON 100K 5% 1/4W
R861 1-260-076-11 CARBON 10 5% 1/2W
R864 1-249-437-11 CARBON 47K 5% 1/4W
R871 1-249-437-11 CARBON 47K 5% 1/4W
R872 1-249-437-11 CARBON 47K 5% 1/4W
R873 1-249-437-11 CARBON 47K 5% 1/4W
R881 1-249-429-11 CARBON 10K 5% 1/4W
R882 1-249-437-11 CARBON 47K 5% 1/4W
R883 1-249-429-11 CARBON 10K 5% 1/4W
R884 1-249-441-11 CARBON 100K 5% 1/4W
! R885 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(TH)
! R885 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
R886 1-249-429-11 CARBON 10K 5% 1/4W
R887 1-249-437-11 CARBON 47K 5% 1/4W
R888 1-249-429-11 CARBON 10K 5% 1/4W
R889 1-249-441-11 CARBON 100K 5% 1/4W
! R890 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(TH)
! R890 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(E,EA,MY,SP,IA)
R891 1-249-429-11 CARBON 10K 5% 1/4W
R892 1-249-437-11 CARBON 47K 5% 1/4W
R893 1-249-429-11 CARBON 10K 5% 1/4W
R894 1-249-441-11 CARBON 100K 5% 1/4W
! R895 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(TH)
! R895 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(E,EA,MY,SP,IA)
R896 1-247-863-91 CARBON 22K 5% 1/4W
R897 1-247-863-91 CARBON 22K 5% 1/4W
< RELAY >
RY881 1-515-920-11 RELAY (TH)
RY881 1-755-168-11 RELAY
RY882 1-515-920-11 RELAY (24V)
RY883 1-515-920-11 RELAY (24V)
< TERMINAL >
TM801 1-537-240-11 TERMINAL BOARD (CHECKER PIN)
(FRONT SPEAKER)
TM802 1-537-510-11 TERMINAL BOARD (SPEAKER)(6P)
(SURROUND SPEAKER)
**************************************************************
A-2007-800-A LEAF SW BOARD, COMPLETE
***********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
FRONT AMP
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
LEAF SW
