– 105 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CONNECTOR >
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-991-33 DIODE 1SS133T-77
D1002 8-719-991-33 DIODE 1SS133T-77
< CABLE HOLDER >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R907 1-249-441-11 CARBON 100K 5% 1/4W
R1001 1-247-815-91 CARBON 220 5% 1/4W
R1002 1-247-815-91 CARBON 220 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-91 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
(TAPE SPEED (NORMAL))
RV1002 1-241-785-11 RES, ADJ, CARBON 10K (TAPE SPEED (HIGH))
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A PLAY)
S1004 1-771-205-11 SWITCH, LEAF (B PLAY)
S1005 1-771-205-11 SWITCH, LEAF (A 120/70)
S1006 1-771-333-11 SWITCH, LEAF (REC A)
S1008 1-771-205-11 SWITCH, LEAF (REC B)
S1009 1-771-205-11 SWITCH, LEAF (B 120/70)
**************************************************************
A-4417-910-A MAIN BOARD, COMPLETE (TH)
********************
A-4417-918-A MAIN BOARD, COMPLETE (EA)
********************
A-4417-955-A MAIN BOARD, COMPLETE (E,MY,SP,IA)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C102 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C103 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C104 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C111 1-137-195-11 FILM 0.56uF 5% 50V
C112 1-136-158-00 FILM 0.027uF 5% 50V
C113 1-136-167-00 FILM 0.15uF 5% 50V
C114 1-130-480-00 MYLAR 0.0056uF 5% 50V
C115 1-136-159-00 FILM 0.033uF 5% 50V
C116 1-130-473-00 MYLAR 0.0015uF 5% 50V
C117 1-136-153-00 FILM 0.01uF 5% 50V
C118 1-110-341-11 MYLAR 330PF 5% 50V
C119 1-130-479-00 MYLAR 0.0047uF 5% 50V
C120 1-130-477-00 MYLAR 0.0033uF 5% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C123 1-136-169-00 FILM 0.22uF 5% 50V
C124 1-136-169-00 FILM 0.22uF 5% 50V
C125 1-126-964-11 ELECT 10uF 20% 50V
C127 1-136-153-00 FILM 0.01uF 5% 50V
C128 1-136-495-11 FILM 0.068uF 5% 50V
C131 1-104-664-11 ELECT 47uF 20% 16V
C132 1-104-664-11 ELECT 47uF 20% 16V
C134 1-126-964-11 ELECT 10uF 20% 50V
C141 1-126-959-11 ELECT 0.47uF 20% 50V
C151 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C152 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C153 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C161 1-137-195-11 FILM 0.56uF 5% 50V
C162 1-136-158-00 FILM 0.027uF 5% 50V
C163 1-136-167-00 FILM 0.15uF 5% 50V
C164 1-130-480-00 MYLAR 0.0056uF 5% 50V
C165 1-136-159-00 FILM 0.033uF 5% 50V
C166 1-130-473-00 MYLAR 0.0015uF 5% 50V
C167 1-136-153-00 FILM 0.01uF 5% 50V
C168 1-110-341-11 MYLAR 330PF 5% 50V
C169 1-130-479-00 MYLAR 0.0047uF 5% 50V
C170 1-130-477-00 MYLAR 0.0033uF 5% 50V
C171 1-126-964-11 ELECT 10uF 20% 50V
C172 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C173 1-136-169-00 FILM 0.22uF 5% 50V
C174 1-136-169-00 FILM 0.22uF 5% 50V
C175 1-126-964-11 ELECT 10uF 20% 50V
C191 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C204 1-126-959-11 ELECT 0.47uF 20% 50V
C207 1-136-165-00 FILM 0.1uF 5% 50V
C208 1-136-165-00 FILM 0.1uF 5% 50V
C210 1-126-959-11 ELECT 0.47uF 20% 50V
C212 1-126-959-11 ELECT 0.47uF 20% 50V
C215 1-126-959-11 ELECT 0.47uF 20% 50V
C217 1-126-959-11 ELECT 0.47uF 20% 50V
C218 1-136-165-00 FILM 0.1uF 5% 50V
C219 1-163-038-91 CERAMIC CHIP 0.1uF 25V
MAIN
LEAF SW
To Next Page
