– 109 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
R277 1-216-073-00 METAL CHIP 10K 5% 1/10W
R278 1-216-073-00 METAL CHIP 10K 5% 1/10W
R279 1-216-073-00 METAL CHIP 10K 5% 1/10W
R281 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R282 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R283 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R284 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R285 1-216-097-91 RES,CHIP 100K 5% 1/10W
R286 1-216-073-00 METAL CHIP 10K 5% 1/10W
R287 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R288 1-216-097-91 RES,CHIP 100K 5% 1/10W
R289 1-216-073-00 METAL CHIP 10K 5% 1/10W
R291 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R292 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R293 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R294 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R295 1-216-097-91 RES,CHIP 100K 5% 1/10W
R296 1-216-073-00 METAL CHIP 10K 5% 1/10W
R301 1-216-085-00 METAL CHIP 33K 5% 1/10W
R302 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R303 1-216-025-91 RES,CHIP 100 5% 1/10W
R304 1-216-025-91 RES,CHIP 100 5% 1/10W
R305 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R306 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R307 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R308 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R309 1-216-081-00 METAL CHIP 22K 5% 1/10W
R311 1-216-121-91 RES,CHIP 1M 5% 1/10W
R312 1-216-102-00 RES,CHIP 160K 5% 1/10W
R313 1-216-097-91 RES,CHIP 100K 5% 1/10W
R315 1-216-073-00 METAL CHIP 10K 5% 1/10W
R316 1-216-079-00 METAL CHIP 18K 5% 1/10W
R317 1-216-073-00 METAL CHIP 10K 5% 1/10W
R318 1-216-073-00 METAL CHIP 10K 5% 1/10W
R319 1-216-111-00 METAL CHIP 390K 5% 1/10W
R321 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R322 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R341 1-216-094-00 RES,CHIP 75K 5% 1/10W
R342 1-216-094-00 RES,CHIP 75K 5% 1/10W
R343 1-216-089-91 RES,CHIP 47K 5% 1/10W
R344 1-216-089-91 RES,CHIP 47K 5% 1/10W
R345 1-216-089-91 RES,CHIP 47K 5% 1/10W
R346 1-216-049-91 RES,CHIP 1K 5% 1/10W
R347 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R348 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R351 1-216-085-00 METAL CHIP 33K 5% 1/10W
R352 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R353 1-216-025-91 RES,CHIP 100 5% 1/10W
R354 1-216-025-91 RES,CHIP 100 5% 1/10W
R355 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R356 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R357 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R358 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R359 1-216-085-00 METAL CHIP 33K 5% 1/10W
R371 1-216-045-00 METAL CHIP 680 5% 1/10W
R372 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R373 1-216-045-00 METAL CHIP 680 5% 1/10W
R374 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R375 1-216-089-91 RES,CHIP 47K 5% 1/10W
R376 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R377 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R378 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R379 1-216-045-00 METAL CHIP 680 5% 1/10W
R380 1-216-045-00 METAL CHIP 680 5% 1/10W
R381 1-216-089-91 RES,CHIP 47K 5% 1/10W
R382 1-216-089-91 RES,CHIP 47K 5% 1/10W
R383 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R384 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R385 1-216-045-00 METAL CHIP 680 5% 1/10W
R386 1-216-045-00 METAL CHIP 680 5% 1/10W
R387 1-216-089-91 RES,CHIP 47K 5% 1/10W
R401 1-216-025-91 RES,CHIP 100 5% 1/10W
R402 1-216-085-00 METAL CHIP 33K 5% 1/10W
R411 1-240-578-31 CARBON 150 5% 1/2W
R412 1-240-578-31 CARBON 150 5% 1/2W
R413 1-240-577-31 CARBON 56 5% 1/2W
R414 1-216-049-91 RES,CHIP 1K 5% 1/10W
R415 1-216-073-00 METAL CHIP 10K 5% 1/10W
R416 1-216-089-91 RES,CHIP 47K 5% 1/10W
R417 1-216-049-91 RES,CHIP 1K 5% 1/10W
R418 1-216-089-91 RES,CHIP 47K 5% 1/10W
R419 1-216-089-91 RES,CHIP 47K 5% 1/10W
R421 1-216-085-00 METAL CHIP 33K 5% 1/10W
R431 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R432 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R433 1-216-097-91 RES,CHIP 100K 5% 1/10W
R451 1-216-025-91 RES,CHIP 100 5% 1/10W
R452 1-216-085-00 METAL CHIP 33K 5% 1/10W
R461 1-240-578-31 CARBON 150 5% 1/2W
R462 1-240-578-31 CARBON 150 5% 1/2W
R463 1-240-577-31 CARBON 56 5% 1/2W
R464 1-216-049-91 RES,CHIP 1K 5% 1/10W
R468 1-216-089-91 RES,CHIP 47K 5% 1/10W
R469 1-216-089-91 RES,CHIP 47K 5% 1/10W
R502 1-216-041-00 METAL CHIP 470 5% 1/10W
R503 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R504 1-216-025-91 RES,CHIP 100 5% 1/10W
R505 1-216-089-91 RES,CHIP 47K 5% 1/10W
R506 1-216-089-91 RES,CHIP 47K 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-033-00 METAL CHIP 220 5% 1/10W
R509 1-216-097-91 RES,CHIP 100K 5% 1/10W
R510 1-216-295-91 SHORT 0
R511 1-216-109-00 METAL CHIP 330K 5% 1/10W
R513 1-216-295-91 SHORT 0
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-025-91 RES,CHIP 100 5% 1/10W
R522 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R526 1-216-025-91 RES,CHIP 100 5% 1/10W
R527 1-216-025-91 RES,CHIP 100 5% 1/10W
R528 1-216-073-00 METAL CHIP 10K 5% 1/10W
R529 1-216-025-91 RES,CHIP 100 5% 1/10W
R530 1-216-025-91 RES,CHIP 100 5% 1/10W
