– 110 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R536 1-216-025-91 RES,CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R539 1-216-025-91 RES,CHIP 100 5% 1/10W
R542 1-216-025-91 RES,CHIP 100 5% 1/10W
R543 1-216-025-91 RES,CHIP 100 5% 1/10W
R549 1-216-049-91 RES,CHIP 1K 5% 1/10W
R550 1-216-025-91 RES,CHIP 100 5% 1/10W
R551 1-216-025-91 RES,CHIP 100 5% 1/10W
R552 1-216-025-91 RES,CHIP 100 5% 1/10W
R553 1-216-025-91 RES,CHIP 100 5% 1/10W
R554 1-216-025-91 RES,CHIP 100 5% 1/10W
R555 1-216-025-91 RES,CHIP 100 5% 1/10W
R559 1-216-025-91 RES,CHIP 100 5% 1/10W
R560 1-216-025-91 RES,CHIP 100 5% 1/10W
R561 1-216-025-91 RES,CHIP 100 5% 1/10W
R563 1-216-025-91 RES,CHIP 100 5% 1/10W
R565 1-216-025-91 RES,CHIP 100 5% 1/10W
R566 1-216-025-91 RES,CHIP 100 5% 1/10W
R567 1-216-025-91 RES,CHIP 100 5% 1/10W
R568 1-216-025-91 RES,CHIP 100 5% 1/10W
R569 1-216-025-91 RES,CHIP 100 5% 1/10W
R570 1-216-025-91 RES,CHIP 100 5% 1/10W
R571 1-216-025-91 RES,CHIP 100 5% 1/10W
R572 1-216-073-00 METAL CHIP 10K 5% 1/10W
R573 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R574 1-216-073-00 METAL CHIP 10K 5% 1/10W
R575 1-216-073-00 METAL CHIP 10K 5% 1/10W
R576 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-073-00 METAL CHIP 10K 5% 1/10W
R578 1-216-073-00 METAL CHIP 10K 5% 1/10W
R586 1-216-025-91 RES,CHIP 100 5% 1/10W
R587 1-216-025-91 RES,CHIP 100 5% 1/10W
R588 1-216-025-91 RES,CHIP 100 5% 1/10W
R589 1-216-025-91 RES,CHIP 100 5% 1/10W
R590 1-216-025-91 RES,CHIP 100 5% 1/10W
R591 1-216-025-91 RES,CHIP 100 5% 1/10W
R594 1-216-295-91 SHORT 0
R595 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R596 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R597 1-216-065-91 RES,CHIP 47K 5% 1/10W
R598 1-216-029-00 METAL CHIP 150 5% 1/10W
(E,MY,SP,IA)
R598 1-216-037-00 METAL CHIP 330 5% 1/10W
(TH)
R598 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
(EA)
R901 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R902 1-216-045-00 METAL CHIP 680 5% 1/10W
R903 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R904 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R905 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R906 1-216-043-91 RES,CHIP 560 5% 1/10W
R907 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R908 1-216-073-00 METAL CHIP 10K 5% 1/10W
R909 1-216-075-00 METAL CHIP 12K 5% 1/10W
R910 1-216-073-00 METAL CHIP 10K 5% 1/10W
R911 1-216-081-00 METAL CHIP 22K 5% 1/10W
R912 1-216-049-91 RES,CHIP 1K 5% 1/10W
R913 1-216-033-00 METAL CHIP 220 5% 1/10W
R914 1-216-295-91 SHORT 0
R915 1-216-081-00 METAL CHIP 22K 5% 1/10W
R916 1-216-049-91 RES,CHIP 1K 5% 1/10W
R917 1-216-295-91 RES,CHIP 0 (2012)
R931 1-216-081-00 METAL CHIP 22K 5% 1/10W
R932 1-216-081-00 METAL CHIP 22K 5% 1/10W
R933 1-216-081-00 METAL CHIP 22K 5% 1/10W
R951 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R952 1-216-045-00 METAL CHIP 680 5% 1/10W
R953 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R954 1-216-138-00 METAL CHIP 3.3 5% 1/8W
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< VIBRATOR >
X510 1-567-098-41 VIBRATOR, CRYSTAL (32.768MHz)
X513 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-109-89 DIODE RD5.6ESB2
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE)
**************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
MAIN
MOTOR (SLIDE)
MOTOR (TURN)
To Next Page
