Sony HCD-VX90AV - Page 81

– 111 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PANEL
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-109-69 DIODE RD3.6ES-B2
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
A-4417-959-A PANEL BOARD, COMPLETE
*********************
4-214-439-01 HOLDER, FL TUBE
* 4-949-935-81 CUSHION (FL)
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 20% 16V
C604 1-162-294-31 CERAMIC 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C610 1-124-589-11 ELECT 47uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 20% 16V
C612 1-162-306-11 CERAMIC 0.01uF 20% 16V
C614 1-162-306-11 CERAMIC 0.01uF 20% 16V
C615 1-162-306-11 CERAMIC 0.01uF 20% 16V
C616 1-126-157-11 ELECT 10uF 20% 16V
C617 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C618 1-126-157-11 ELECT 10uF 20% 16V
C619 1-126-157-11 ELECT 10uF 20% 16V
C620 1-126-163-11 ELECT 4.7uF 20% 50V
C625 1-126-157-11 ELECT 10uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
C628 1-126-157-11 ELECT 10uF 20% 16V
C630 1-162-306-11 CERAMIC 0.01uF 20% 16V
C631 1-162-306-11 CERAMIC 0.01uF 20% 16V
C632 1-162-306-11 CERAMIC 0.01uF 20% 16V
C651 1-162-282-31 CERAMIC 100PF 10% 50V
C652 1-162-282-31 CERAMIC 100PF 10% 50V
C653 1-162-282-31 CERAMIC 100PF 10% 50V
C654 1-162-282-31 CERAMIC 100PF 10% 50V
C655 1-162-282-31 CERAMIC 100PF 10% 50V
C656 1-162-282-31 CERAMIC 100PF 10% 50V
C657 1-162-282-31 CERAMIC 100PF 10% 50V
C658 1-162-282-31 CERAMIC 100PF 10% 50V
C659 1-162-282-31 CERAMIC 100PF 10% 50V
C660 1-162-282-31 CERAMIC 100PF 10% 50V
C661 1-162-282-31 CERAMIC 100PF 10% 50V
C662 1-162-282-31 CERAMIC 100PF 10% 50V
C663 1-162-282-31 CERAMIC 100PF 10% 50V
C664 1-162-282-31 CERAMIC 100PF 10% 50V
C665 1-162-282-31 CERAMIC 100PF 10% 50V
C666 1-162-282-31 CERAMIC 100PF 10% 50V
C667 1-162-282-31 CERAMIC 100PF 10% 50V
C668 1-162-282-31 CERAMIC 100PF 10% 50V
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-164-159-21 CERAMIC 0.1uF 50V
C711 1-162-294-31 CERAMIC 0.001uF 10% 50V
C712 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C713 1-126-160-11 ELECT 1uF 20% 50V
C714 1-136-495-11 FILM 0.068uF 5% 50V
C715 1-124-465-00 ELECT 0.47uF 20% 50V
C716 1-124-465-00 ELECT 0.47uF 20% 50V
C717 1-136-167-00 FILM 0.15uF 5% 50V
C718 1-162-294-31 CERAMIC 0.001uF 10% 50V
C719 1-126-160-11 ELECT 1uF 20% 50V
C720 1-161-494-00 CERAMIC 0.022uF 25V
C721 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C722 1-136-495-11 FILM 0.068uF 5% 50V
C723 1-124-589-11 ELECT 47uF 20% 16V
C724 1-136-165-00 FILM 0.1uF 5% 50V
C725 1-124-589-11 ELECT 47uF 20% 16V
C731 1-162-306-11 CERAMIC 0.01uF 20% 16V
C732 1-124-257-00 ELECT 2.2uF 20% 50V
C733 1-162-294-31 CERAMIC 0.001uF 10% 50V
C734 1-162-215-31 CERAMIC 47PF 5% 50V
C735 1-124-261-00 ELECT 10uF 20% 50V
C736 1-162-290-31 CERAMIC 470PF 10% 50V
C737 1-124-463-00 ELECT 0.1uF 20% 50V
C738 1-124-257-00 ELECT 2.2uF 20% 50V
C739 1-162-215-31 CERAMIC 47PF 5% 50V
C741 1-124-261-00 ELECT 10uF 20% 50V
C742 1-162-282-31 CERAMIC 100PF 10% 50V
C743 1-124-257-00 ELECT 2.2uF 20% 50V
C744 1-162-306-11 CERAMIC 0.01uF 20% 16V
C745 1-124-257-00 ELECT 2.2uF 20% 50V
C747 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN601 1-784-745-11 CONNECTOR, FFC 23P
< DIODE >
D610 8-719-050-84 DIODE RB441Q-40T-77
D611 8-719-073-47 DIODE SML72923C-TP15 (REC/PAUSE START)
D612 8-719-056-13 DIODE SML79423C-TP15 (^ CD)
D613 8-719-058-03 DIODE SEL5423E-TP15 (TAPE B ()
D614 8-719-058-03 DIODE SEL5423E-TP15 (TAPE B 9)
D615 8-719-058-03 DIODE SEL5423E-TP15 (TAPE A ()
D616 8-719-058-03 DIODE SEL5423E-TP15 (TAPE A 9)
D617 8-719-057-97 DIODE SEL5923A-TP15 (PBC OFF)
D618 8-719-057-97 DIODE SEL5923A-TP15 (PBC)
D619 8-719-057-97 DIODE SEL5923A-TP15 (SYNC BASE L)
D620 8-719-057-97 DIODE SEL5923A-TP15 (SYNC BASE H)
D621 8-719-057-97 DIODE SEL5923A-TP15 (SYNC EQ)
MOTOR (TURN)
