– 116 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
VIDEO
L501 1-216-296-91 SHORT 0
L502 1-216-296-91 SHORT 0
L503 1-216-296-91 SHORT 0
L504 1-410-375-11 INDUCTOR CHIP 3.3uH
L505 1-216-296-91 SHORT 0
L506 1-216-296-91 SHORT 0
L507 1-216-296-91 SHORT 0
L508 1-216-296-91 SHORT 0
L509 1-216-296-91 SHORT 0
L510 1-216-296-91 SHORT 0
< TRANSISTOR >
Q301 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q302 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q303 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q304 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q306 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q307 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q308 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q310 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q453 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q454 8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q502 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q531 8-729-140-75 TRANSISTOR 2SD999-CLCK
< RESISTOR >
R101 1-216-073-00 METAL CHIP 10K 5% 1/10W
R102 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R103 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R105 1-216-295-91 SHORT 0
R201 1-216-073-00 METAL CHIP 10K 5% 1/10W
R202 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R203 1-208-441-61 RES,CHIP 1.5K 2% 1/10W
R205 1-216-295-91 SHORT 0
R301 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R302 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R305 1-216-049-91 RES,CHIP 1K 5% 1/10W
R306 1-216-073-00 METAL CHIP 10K 5% 1/10W
R307 1-216-049-91 RES,CHIP 1K 5% 1/10W
R308 1-216-049-91 RES,CHIP 1K 5% 1/10W
R309 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R312 1-216-073-00 METAL CHIP 10K 5% 1/10W
R313 1-216-049-91 RES,CHIP 1K 5% 1/10W
R314 1-216-049-91 RES,CHIP 1K 5% 1/10W
R315 1-216-047-91 RES,CHIP 820 5% 1/10W
R316 1-216-657-11 METAL CHIP 1.8K 0.5% 1/10W
R317 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R318 1-216-033-00 METAL CHIP 220 5% 1/10W
R319 1-216-049-91 RES,CHIP 1K 5% 1/10W
R320 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R321 1-216-049-91 RES,CHIP 1K 5% 1/10W
R324 1-216-022-00 METAL CHIP 75 5% 1/10W
R325 1-216-295-91 SHORT 0
R327 1-216-049-91 RES,CHIP 1K 5% 1/10W
R328 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R329 1-216-649-11 METAL CHIP 820 0.5% 1/10W
R332 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R333 1-216-046-00 METAL CHIP 750 5% 1/10W
R335 1-216-073-00 METAL CHIP 10K 5% 1/10W
R336 1-216-073-00 METAL CHIP 10K 5% 1/10W
R340 1-216-022-00 METAL CHIP 75 5% 1/10W
R341 1-216-121-91 RES,CHIP 1M 5% 1/10W
R342 1-216-022-00 METAL CHIP 75 5% 1/10W
R403 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R404 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R405 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R406 1-216-081-00 METAL CHIP 22K 5% 1/10W
R407 1-216-073-00 METAL CHIP 10K 5% 1/10W
R408 1-216-073-00 METAL CHIP 10K 5% 1/10W
R409 1-216-049-91 RES,CHIP 1K 5% 1/10W
R410 1-216-049-91 RES,CHIP 1K 5% 1/10W
R411 1-216-073-00 METAL CHIP 10K 5% 1/10W
R412 1-216-073-00 METAL CHIP 10K 5% 1/10W
R414 1-216-081-00 METAL CHIP 22K 5% 1/10W
R415 1-216-081-00 METAL CHIP 22K 5% 1/10W
R423 1-216-073-00 METAL CHIP 10K 5% 1/10W
R424 1-216-073-00 METAL CHIP 10K 5% 1/10W
R425 1-216-073-00 METAL CHIP 10K 5% 1/10W
R426 1-216-073-00 METAL CHIP 10K 5% 1/10W
R457 1-216-025-91 RES,CHIP 100 5% 1/10W
R458 1-216-025-91 RES,CHIP 100 5% 1/10W
R459 1-216-025-91 RES,CHIP 100 5% 1/10W
R461 1-216-025-91 RES,CHIP 100 5% 1/10W
R462 1-216-025-91 RES,CHIP 100 5% 1/10W
R463 1-216-025-91 RES,CHIP 100 5% 1/10W
R464 1-216-025-91 RES,CHIP 100 5% 1/10W
R501 1-216-025-91 RES,CHIP 100 5% 1/10W
R502 1-216-025-91 RES,CHIP 100 5% 1/10W
R503 1-216-025-91 RES,CHIP 100 5% 1/10W
R504 1-216-025-91 RES,CHIP 100 5% 1/10W
R505 1-216-025-91 RES,CHIP 100 5% 1/10W
R506 1-216-025-91 RES,CHIP 100 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-081-00 METAL CHIP 22K 5% 1/10W
R509 1-216-081-00 METAL CHIP 22K 5% 1/10W
R510 1-216-081-00 METAL CHIP 22K 5% 1/10W
R511 1-216-081-00 METAL CHIP 22K 5% 1/10W
R512 1-216-081-00 METAL CHIP 22K 5% 1/10W
R513 1-216-081-00 METAL CHIP 22K 5% 1/10W
R514 1-216-081-00 METAL CHIP 22K 5% 1/10W
R516 1-216-073-00 METAL CHIP 10K 5% 1/10W
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-073-00 METAL CHIP 10K 5% 1/10W
R519 1-216-025-91 RES,CHIP 100 5% 1/10W
R520 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R523 1-216-013-00 METAL CHIP 33 5% 1/10W
R530 1-216-081-00 METAL CHIP 22K 5% 1/10W
R531 1-216-025-91 RES,CHIP 100 5% 1/10W
R532 1-216-025-91 RES,CHIP 100 5% 1/10W
R533 1-216-025-91 RES,CHIP 100 5% 1/10W
R534 1-216-073-00 METAL CHIP 10K 5% 1/10W
R535 1-216-073-00 METAL CHIP 10K 5% 1/10W
R536 1-216-033-00 METAL CHIP 220 5% 1/10W
