– 117 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
VIDEO
R537 1-216-025-91 RES,CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R542 1-216-049-91 RES,CHIP 1K 5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R545 1-216-025-91 RES,CHIP 100 5% 1/10W
R546 1-216-049-91 RES,CHIP 1K 5% 1/10W
R547 1-216-295-91 SHORT 0
R548 1-216-049-91 RES,CHIP 1K 5% 1/10W
R549 1-216-025-91 RES,CHIP 100 5% 1/10W
R550 1-216-025-91 RES,CHIP 100 5% 1/10W
R551 1-216-025-91 RES,CHIP 100 5% 1/10W
R552 1-216-025-91 RES,CHIP 100 5% 1/10W
R554 1-216-025-91 RES,CHIP 100 5% 1/10W
R555 1-216-121-91 RES,CHIP 1M 5% 1/10W
R556 1-216-025-91 RES,CHIP 100 5% 1/10W
R557 1-216-025-91 RES,CHIP 100 5% 1/10W
R558 1-216-073-00 METAL CHIP 10K 5% 1/10W
R559 1-216-073-00 METAL CHIP 10K 5% 1/10W
R560 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R561 1-216-049-91 RES,CHIP 1K 5% 1/10W
R562 1-216-025-91 RES,CHIP 100 5% 1/10W
R563 1-216-025-91 RES,CHIP 100 5% 1/10W
R564 1-216-025-91 RES,CHIP 100 5% 1/10W
R565 1-216-025-91 RES,CHIP 100 5% 1/10W
R566 1-216-025-91 RES,CHIP 100 5% 1/10W
R567 1-216-073-00 METAL CHIP 10K 5% 1/10W
R568 1-216-073-00 METAL CHIP 10K 5% 1/10W
R569 1-216-073-00 METAL CHIP 10K 5% 1/10W
R572 1-216-073-00 METAL CHIP 10K 5% 1/10W
R573 1-216-073-00 METAL CHIP 10K 5% 1/10W
R574 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S501 1-571-395-11 SWITCH, SLIDE
(SYSTEM SELECT NTSCnAUTOnPAL)
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC (10MHz)
X503 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
**************************************************************
MISCELLANEOUS
*************
5 1-233-545-11 TUNER UNIT (FM/AM) (TH)
5 1-233-546-11 TUNER UNIT (FM/MW/SW) (EXCEPT TH)
9 1-783-949-11 WIRE (FLAT TYPE) (13 CORE)
10 1-775-212-11 WIRE (FLAT TYPE) (23 CORE)
54 1-783-570-11 WIRE (FLAT TYPE) (19 CORE)
55 1-769-976-11 WIRE (FLAT TYPE) (13 CORE) (TH)
55 1-773-008-11 WIRE (FLAT TYPE) (15 CORE) (140 mm)
(EXCEPT TH)
56 1-773-049-11 WIRE (FLAT TYPE) (17 CORE)
58 1-569-007-11 ADAPTOR, CONVERSION 2P (E,IA)
58 1-569-008-21 ADAPTOR, CONVERSION 2P (EA,SP,MY)
! 59 1-575-651-11 CORD, POWER (EA,SP,MY)
! 59 1-575-653-11 CORD, POWER (E,IA,TH)
62 1-773-023-11 WIRE (FLAT TYPE) (15 CORE) (310 mm)
116 1-773-189-11 WIRE (FLAT TYPE) (23 CORE)
121 1-674-232-11 PUSH CATCH STOP BOARD
257 1-452-925-21 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
FL601 1-517-831-31 INDICATOR TUBE, FLUORESCENT
HP101 A-2056-681-B DECK (A) ASSY, HEAD (230AWR2)
HP101 A-2056-683-B DECK (A) ASSY, HEAD (230PWR2)
HRPE101 A-2056-682-B DECK (B) ASSY, HEAD (230AWR2)
HRPE101 A-2056-684-B DECK (B) ASSY, HEAD (230PWR2)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLIDE)
M901 1-763-072-11 FAN, DC
S811 1-473-335-11 ENCODER, ROTARY
! T951 1-433-555-11 TRANSFORMER, POWER
**************************************************************
*************
HARDWARE LIST
*************
#1 7-685-871-01 SCREW +BVTT 3X6 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-880-09 SCREW +BVTT 4X6 (S)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#5 7-685-852-04 SCREW +BVTT 2X5 (S)
#6 7-621-775-10 SCREW +B 2.6X4
#7 7-682-553-04 SCREW +P 3X20
#8 7-685-851-04 SCREW +BVTT 2X4 (S)
#9 7-628-254-15 SCREW +PS 2.6X6
#10 7-628-254-50 SCREW +PS 2.6X16
#11 7-685-861-01 SCREW +BVTT 2.6X5 (S)
#12 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
