Sony HCD-XB4 - Tape Mechanism and Cassette Lid Disassembly; TAPE MECHANISM DECK SECTION; CASSETTE LID ASSY

– 24 –
TAPE MECHANISM DECK SECTION
4 three screws
(BVTP 2.6
× 8)
4 three screws
(BVTP 2.6
× 8)
5 Remove the tape mechanism
deck section to direction of the arrow
A .
2 Open the
cassette lids.
1 Push the
two buttons.
A
1 two springs
3 two bracket
2 two screws
(BVTP 2.6
× 8)
CASSETTE LID ASS’Y
3 two flat wires
(CN601, 1001)
