Sony HCD-XB4 - PANEL POWER AMP

– 105 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
CN602 1-506-486-11 PIN, CONNECTOR 7P
* CN603 1-568-944-11 PIN, CONNECTOR 6P
* CN604 1-568-946-11 PIN, CONNECTOR 8P
< DIODE >
D601 8-719-987-63 DIODE 1N4148M
D602 8-719-987-63 DIODE 1N4148M
D606 8-719-987-63 DIODE 1N4148M
D607 8-719-987-63 DIODE 1N4148M
D611 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
D612 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
D613 8-719-058-04 DIODE SEL5223S-TP15 (ENTER/NEXT)
D614 8-719-058-04 DIODE SEL5223S-TP15 (GROOVE)
D615 8-719-058-04 DIODE SEL5223S-TP15 (SUPER WOOFER)
D616 8-719-058-04 DIODE SEL5223S-TP15 (EFFECT)
D617 8-719-058-04 DIODE SEL5223S-TP15 (ENTER)
D618 8-719-058-04 DIODE SEL5223S-TP15 (FILE 1)
D619 8-719-058-04 DIODE SEL5223S-TP15 (FILE 2)
D620 8-719-058-04 DIODE SEL5223S-TP15 (FILE 3)
D621 8-719-058-04 DIODE SEL5223S-TP15 (FILE 4)
D622 8-719-058-04 DIODE SEL5223S-TP15 (FILE 5)
D623 8-719-058-04 DIODE SEL5223S-TP15 (P.FILE)
D624 8-719-058-04 DIODE SEL5223S-TP15 (MENU 2)
D625 8-719-058-04 DIODE SEL5223S-TP15 (MENU 1)
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR (SMALL TYPE)
< FILTER >
FL601 1-517-619-11 INDICATOR TUBE, FLUORESCENT
< COIL >
L601 1-410-509-11 MICRO INDUCTOR 10uH
< IC >
IC601 8-759-446-26 IC TMP87CH74-6544
IC602 8-759-459-84 IC NJL56H400
< TRANSISTOR >
Q601 8-729-119-78 TRANSISTOR 2SC403SP-51
Q602 8-729-118-00 TRANSISTOR 2SB1116-L
Q603 8-729-118-00 TRANSISTOR 2SB1116-L
Q604 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q605 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q606 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q607 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q608 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q609 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q610 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q611 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q614 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q617 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q618 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q619 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q621 8-729-119-77 TRANSISTOR 2SA1175-FEK
< RESISTOR >
R601 1-249-415-11 CARBON 680 5% 1/4W
R602 1-249-431-11 CARBON 15K 5% 1/4W
R603 1-247-903-00 CARBON 1M 5% 1/4W
R608 1-249-429-11 CARBON 10K 5% 1/4W
R609 1-247-843-11 CARBON 3.3K 5% 1/4W
R610 1-247-843-11 CARBON 3.3K 5% 1/4W
R611 1-249-429-11 CARBON 10K 5% 1/4W
R612 1-249-429-11 CARBON 10K 5% 1/4W
R613 1-249-401-11 CARBON 47 5% 1/4W
R614 1-249-429-11 CARBON 10K 5% 1/4W
R615 1-249-429-11 CARBON 10K 5% 1/4W
R616 1-249-429-11 CARBON 10K 5% 1/4W
R617 1-249-429-11 CARBON 10K 5% 1/4W
R621 1-249-421-11 CARBON 2.2K 5% 1/4W
R622 1-249-437-11 CARBON 47K 5% 1/4W
R623 1-247-895-91 CARBON 470K 5% 1/4W
R624 1-249-421-11 CARBON 2.2K 5% 1/4W
R625 1-249-437-11 CARBON 47K 5% 1/4W
R626 1-247-895-91 CARBON 470K 5% 1/4W
R633 1-247-897-11 CARBON 560K 5% 1/4W
R634 1-247-897-11 CARBON 560K 5% 1/4W
R636 1-249-435-11 CARBON 33K 5% 1/4W
R637 1-247-895-91 CARBON 470K 5% 1/4W
R641 1-249-427-11 CARBON 6.8K 5% 1/4W
R642 1-247-815-91 CARBON 220 5% 1/4W
R643 1-249-410-11 CARBON 270 5% 1/4W
R644 1-249-412-11 CARBON 390 5% 1/4W
R645 1-249-413-11 CARBON 470 5% 1/4W
R646 1-249-415-11 CARBON 680 5% 1/4W
R647 1-249-416-11 CARBON 820 5% 1/4W
R648 1-249-418-11 CARBON 1.2K 5% 1/4W
R649 1-249-419-11 CARBON 1.5K 5% 1/4W
R650 1-249-427-11 CARBON 6.8K 5% 1/4W
R651 1-247-815-91 CARBON 220 5% 1/4W
R652 1-249-410-11 CARBON 270 5% 1/4W
R653 1-249-412-11 CARBON 390 5% 1/4W
R654 1-249-413-11 CARBON 470 5% 1/4W
R655 1-249-415-11 CARBON 680 5% 1/4W
R656 1-249-416-11 CARBON 820 5% 1/4W
PANEL
