– 111 –
Ref. No. Part No. Description Remark
357 1-452-538-11 MAGNET
! 401 8-820-020-01 OPTICAL PICK-UP KSS-213D/Q-NP
402 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! CNP901 1-558-943-41 CORD, POWER (E, MX, PX)
! CNP901 1-575-042-21 CORD, POWER (US, CND)
! CNP901 1-575-651-21 CORD, POWER (AR)
! CNP901 1-696-845-11 CORD, POWER (AUS)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M201 A-4660-977-A MOTOR ASSY (TABLE)
! T901 1-431-046-11 TRANSFORMER, POWER (US, CND)
! T901 1-431-048-11 TRANSFORMER, POWER (EXCEPT US, CND)
*************************************************************
*************
HARDWARE LIST
*************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
#3 7-685-872-09 SCREW +BVTT 3X8 (S)
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#6 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#8 7-621-775-10 SCREW +B 2.6X4
#9 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#10 7-623-921-01 RING, RETAINING, CAPSTAN
#11 7-621-775-00 SCREW +B 2.6X3
#12 7-621-255-15 SCREW +P 2X3
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-501-374-11 ANTENNA, LOOP
1-501-659-41 ANTENNA (FM)
3-859-536-11 MANUAL, INSTRUCTION (ENGLISH)
3-859-536-21 MANUAL, INSTRUCTION (FRENCH) (CND)
3-859-536-31 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(E, AR, MX, PX)
3-859-536-41 MANUAL, INSTRUCTION (CHINESE) (PX)
* 4-987-613-01 INDIVIDUAL CARTON (US)
* 4-987-615-01 INDIVIDUAL CARTON (AUS)
8-917-581-90 REMOCON, SONY RM-SD70//M SET
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
